9K3806 GENERAL PURPOSE BUCKET ASSEMBLY--1.91 Cubic Meters (2.5 Cubic Yard)--2438 mm (96") Wide--Replaced by 5V7264 shown on Page 247BAN ATTACHMENT

Group No: 9K3806
Part NumberPart NameQty
9K82801 HINGE ASSEM. (L.H. -outer)1
2K41192 BOSS1
2K35923 BOSS1
9K82784 HINGE ASSEM. (L.H. -inner)1
2K41195 BOSS2
2K35926 BOSS2
9K82777 HINGE ASSEM. (R.H. -inner)1
2K41198 BOSS2
2K35929 BOSS2
9K827910 HINGE ASSEM. (R.H. -outer)1
2K359211 BOSS1
2K411912 BOSS1
2K365613 BAR2
8K809414 BAR (L.H.)1
8K645515 CORNER (R.H.)1
8K6456CORNER (L.H.)1
8K816116 CUTTING EDGE1
9K830217 PLATE2
9K828718 PLATE2
5J477219 BOLT8
2J3505NUT8
9H1031WASHER8
1V632420 BAR (R.H.)1
