System And Components
163-6277 CONVERSION AR-CERTIFICATION -GERMAN ROADINGS/N 9RS1-UP
Group No: 163-6277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 6C5712 | 2 REFLECTOR (AMBER) | 6 | |
| 6C5736 | 3 REFLECTOR (RED) | 2 | |
| 6C7159 | 4 PLATE | 1 | |
| 6C7224 | 5 BRACKET AS | 2 | |
| 6C7227 | 6 CHOCK-WHEEL | 2 | |
| 6C7875 | 7 RIVET-POP | 8 | |
| 7C6921 | 8 SPACER (11X20X22.8-MM THK) | 2 | |
| 1034816 | 10 PIN AS | 1 | |
| 6C5575 | CABLE | 1 | |
| 1081786 | 11 FILM-IDENTIFICATION (40-KM/H) | 3 | |
| 1096502 | 12 PANEL-REFLECTOR | 2 | |
| 1098203 | 13 MIRROR GP-REAR VIEW (INTERIOR) | 1 | |
| 1103731 | 14 ROD | 1 | |
| 1131635 | 15 FILM (GERMAN) | 1 | |
| 1137634 | 16 FILM-WARNING (STEERING) | 1 | |
| 1155774 | 17 LAMP AS (24-VOLT) | 2 | |
| 1155777 | 18 HARNESS AS-LIGHTING (FRONT TURN, POSITION LIGHTS) | 1 | |
| 1155776 | HOUSING-PLUG | 1 | |
| 1254439 | 19 LAMP AS (24-VOLT, 5-WATT) | 1 | |
| 2531637 | 21 BRACKET | 2 | |
| 1581202 | 22 REFLECTOR (RED) | 2 | |
| 1612473 | 24 FILM-REFLECTOR (RED, WHITE STRIPES, LH) | 1 | |
| 1612474 | 25 FILM-REFLECTOR (RED, WHITE STRIPES, RH) | 1 | |
| 1747350 | 27 GUARD AS (LH) | 1 | |
| 1747351 | 28 GUARD AS (RH) | 1 | |
| 1841224 | 29 COUNTERWEIGHT (1357-KG) | 1 | |
| 2133390 | 30 BRACKET | 1 | |
| 2133391 | 31 SHEET | 2 | |
| 2135302 | 32 HARNESS AS-LIGHTING (REGISTRATION PLATE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2200473 | 33 HARNESS AS-LIGHTING (REAR TURN, MARKER LIGHTS)(REAR TURN & POSITION LIGHTS) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 3P9554 | 34 GROMMET | 2 | |
| 4B4274 | 35 WASHER (5.5X13X1.2-MM THK) | 4 | |
| 5C2890 | 36 NUT (M6X1-THD) | 14 | |
| 5C8312 | 37 NUT (M4X0.7-THD) | 2 | |
| 5P1075 | 38 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 6V7697 | 39 SCREW-MACHINE (8-32X1.25-IN) | 2 | |
| 6V9672 | 40 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 6V8949 | 41 NUT (M10X1.5-THD) | 2 | |
| 7X7729 | 42 WASHER (11X25X3-MM THK) | 8 | |
| 8T4133 | 43 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4138 | 45 BOLT (M6X1X20-MM) | 12 | |
| 8T5005 | 46 BOLT (M10X1.5X70-MM) | 2 | |
| 9R5008 | 47 SPACER (11X20X6-MM THK) | 2 | |
| 9X6165 | 48 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 49 WASHER (6.6X12X2-MM THK) | 20 | |
| 7X0605 | 50 WASHER-HARD (13X28X1.6-MM THK) | 1 | |
| 8T4121 | 51 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4178 | 52 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4196 | 53 BOLT (M10X1.5X35-MM) | 1 |
