System And Components
551-3670 CASE & PARTS GP-PLANETARYS/N TS31-UP
Group No: 551-3670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4183 | 1 BOLT (M12X1.75X40-MM) | 4 | |
| 4J0527 | 2 SEAL-O-RING | 1 | |
| 3H2652 | 3 SEAL-O-RING | 1 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9G5127 | 5 BREATHER (ATMOSPHERIC AIR)(TRANSMISSION CASE) | 1 | |
| 2379062 | 6 COVER | 1 | |
| 2876408 | 7 TUBE | 1 | |
| 5513669 | 8 TUBE AS | 1 | |
| 1416348 | 9 BOLT (M10X1.5X65-MM) | 1 | |
| 1645567 | 10 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1H8720 | 11 SEAL-O-RING | 2 | |
| 7F8268 | 12 SEAL-O-RING | 1 | |
| 5P8068 | 13 SEAL-O-RING | 1 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 5P9806 | 15 SEAL-O-RING | 1 | |
| 6V0852 | 16 CAP-DUST | 1 | |
| 6V3822 | 17 BOLT (M10X1.5X35-MM) | 4 | |
| 6V3823 | 18 BOLT (M12X1.75X60-MM) | 15 | |
| 6V4248 | 19 BOLT (M10X1.5X25-MM) | 4 | |
| 6V5230 | 20 BOLT (M10X1.5X60-MM) | 15 | |
| 6V5684 | 21 BOLT (M12X1.75X45-MM) | 1 | |
| 6V5839 | 22 WASHER (11X21X2.5-MM THK) | 17 | |
| 6V5842 | 23 BOLT (M10X1.5X40-MM) | 2 | |
| 6V7981 | 24 BOLT (M10X1.5X70-MM) | 4 | |
| 7X2544 | 25 BOLT (M10X1.5X140-MM) | 1 | |
| 9M5024 | 26 SEAL-O-RING | 1 | |
| 1P4582 | 27 FLANGE-HALF | 2 | |
| 3485436 | 28 HOSE | 1 | |
| 4562589 | 29 TUBE AS | 1 | |
| 8T4984 | 30 CLAMP-HOSE | 4 | |
| 5P2937 | 31 ADAPTER-O-RING | 1 | |
| 3J7354 | 32 SEAL-O-RING | 1 |
