112-6958 FENDER GPS/N 5FW1-UP

Group No: 112-6958
Part NumberPart NameQty
5R47871 PLATE4
6V23702 RIVET-POP4
13659053 DEFLECTOR1
13659064 DEFLECTOR (LH)1
8T42235 WASHER-HARD (13.5X25.5X3-MM THK)8
13659096 DEFLECTOR1
13659117 DEFLECTOR (LH)1
13868148 STRIP AS2
13659079 DEFLECTOR2
138681810 ANGLE2
138681911 FLAP2
144944312 BRACKET AS2
8T3597NUT-WELD (M12X1.75-THD)2
166820713 FENDER AS (REAR)1
166820814 FENDER AS (REAR, LH)1
146894115 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)4
172625216 FENDER AS-FRONT (RH)1
172625117 FENDER AS-FRONT (LH)1
8T418918 BOLT (M8X1.25X20-MM)14
115643319 WASHER (11X50X6-MM THK)12
7X772920 WASHER (11X25X3-MM THK)38
8T038921 LOCKNUT (M10X1.5-THD)20
8T413622 BOLT (M10X1.5X25-MM)14
8T413723 BOLT (M10X1.5X20-MM)16
8T413924 BOLT (M12X1.75X30-MM)12
5P107625 WASHER-HARD (13.5X30X4-MM THK)4
5P411626 WASHER-HARD (8.8X20.5X2-MM THK)14
