System And Components
213-6481 CONVERSION AR-ROADINGS/N BAB1-365
Group No: 213-6481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 5P8837 | 2 LOCK PIN | 2 | |
| 6C0076 | 3 CONNECTOR | 1 | |
| 6C5712 | 4 REFLECTOR (AMBER) | 2 | |
| 6C5736 | 5 REFLECTOR (RED) | 2 | |
| 6C7159 | 6 PLATE | 1 | |
| 6C7319 | 7 PLATE AS | 2 | |
| 6C7320 | 8 FILM-STRIPE (RED, WHITE) | 2 | |
| 6C7476 | 9 PLATE | 1 | |
| 6C7485 | 10 BLOCK | 1 | |
| 6C7580 | 11 COVER-WORK LIGHT | 8 | |
| 6C7581 | 12 LAMP GP-REGISTRATION PLATE (24-VOLT, 10-WATT) | 1 | |
| 6C7589 | 13 PLATE | 2 | |
| 6C7590 | 14 FILM (RED, WHITE STRIPES) | 2 | |
| 6C7591 | 15 LAMP GP | 2 | |
| 6C7597 | 16 HARNESS AS-LIGHTING (BUCKET) | 1 | |
| 6C7607 | 17 CHAIN AS | 2 | |
| 6C7608 | 18 SPRING | 2 | |
| 6C8664 | 19 SPACER | 4 | |
| 8F0492 | 20 SPACER (0.531X1.125X0.625-IN THK) | 2 | |
| 9X8937 | 21 TACK | 4 | |
| 1078465 | 22 WIRE AS | 1 | |
| 1242541 | 23 GUARD AS | 1 | |
| 1243112 | 24 BRACKET | 2 | |
| 1244131 | 25 FILM-REFLECTOR (RED, WHITE STRIPES) | 1 | |
| 1393058 | 26 PIN GP-LIFT ARM | 1 | |
| 6C7460 | PIN | 2 | |
| 1489025 | 27 BRACKET (LH) | 1 | |
| 1489026 | 28 BRACKET (RH) | 1 | |
| 2000934 | 29 LIGHTING GP-WARNING BEACON | 1 | |
| 1581202 | 30 REFLECTOR (RED) | 2 | |
| 1597342 | 31 PLATE-INFORMATION (MAXIMUM WEIGHT) | 1 | |
| 1612473 | 32 FILM-REFLECTOR (RED, WHITE STRIPES, LH) | 1 | |
| 1612474 | 33 FILM-REFLECTOR (RED, WHITE STRIPES, RH) | 1 | |
| 1638394 | 34 BRACKET AS | 1 | |
| 1638396 | 35 BRACKET AS | 1 | |
| 1989096 | 36 FILM-IDENTIFICATION (BUCKET, BRACKET) | 1 | |
| 1989098 | 37 FILM-WARNING (KEEP AWAY FROM MACHINE) | 2 | |
| 2133390 | 38 BRACKET | 1 | |
| 2133391 | 39 SHEET | 1 | |
| 2135302 | 40 HARNESS AS-LIGHTING (REGISTRATION PLATE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 0966166 | 41 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1989099 | 42 FILM-INFORMATION (REFLECTOR, 40-KM) | 2 | |
| 3P9554 | 43 GROMMET | 2 | |
| 4B4274 | 44 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5C2890 | 45 NUT (M6X1-THD) | 4 | |
| 5C8312 | 46 NUT (M4X0.7-THD) | 6 | |
| 6V7697 | 47 SCREW-MACHINE (8-32X1.25-IN) | 2 | |
| 6V9672 | 48 SCREW-MACHINE (M4X0.7X16-MM) | 6 | |
| 8M2772 | 49 CLIP (LOOP) | 1 | |
| 8T4121 | 50 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 51 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 52 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4138 | 53 BOLT (M6X1X20-MM) | 4 | |
| 8T4182 | 54 BOLT (M10X1.5X45-MM) | 6 | |
| 8T4191 | 55 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4223 | 56 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 57 NUT (M12X1.75-THD) | 2 | |
| 8T5412 | 58 BOLT (M12X1.75X140-MM) | 2 | |
| 9L6074 | 59 GROMMET | 1 | |
| 9X6165 | 60 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 61 WASHER (6.6X12X2-MM THK) | 4 | |
| 7X7877 | 62 STRIP-EDGE (200 CM) |
