System And Components
164-3018 BRAKE & PLANETARY GPS/N K5K1000-UP
Group No: 164-3018
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8R4568 | 1 PISTON | 1 | |
| 8R9207 | 2 SEAL | 1 | |
| 3253780 | 3 SEAL | 1 | |
| 3341034 | 4 DISC-FRICTION | 1 | |
| 9C8418 | 5 PLATE-REACTION | 1 | |
| 1F5151 | 6 DOWEL | 3 | |
| 1643071 | 7 GEAR-PLANETARY (30-TEETH)(30 TEETH) | 3 | |
| 9C7727 | 8 BUSHING | 3 | |
| 9C9537 | 9 WASHER-THRUST | 6 | |
| 8T2925 | 10 PIN-SPRING | 3 | |
| 8R1888 | 11 SHAFT-PLANETARY | 3 | |
| 8R4571 | 12 CARRIER-PLANETARY | 1 | |
| 9M4335 | 13 DOWEL-REACTION | 2 | |
| 1646476 | 14 GEAR-SUN (18-TEETH) | 1 | |
| 1499112 | 15 DOWEL-HOLLOW | 1 | |
| 1171801 | 16 DOWEL | 1 | |
| 3720730 | 17 GEAR-RING (81-TEETH) | 1 | |
| 2N2658 | 18 BOLT-SOCKET HEAD (8-32X15.88-MM) | 1 | |
| 0966166 | 19 WASHER-HARD (4.5X9X1-MM THK) | 1 | |
| 1120759 | 20 PLUG | 1 | |
| 1381645 | 21 PIN-SPRING | 3 | |
| 1499114 | 22 PIN (BRAKE DISC WEAR INDICATOR) | 1 | |
| 1504651 | 23 SEAL-O-RING | 1 | |
| 2933609 | 24 SPRING | 3 | |
| 1171803 | 25 CUP | 1 | |
| 3253781 | 26 RING-BACKUP | 1 |
