System And Components
502-0337 CONTROL & MTG GP-ELHYD -3-LEVER, WITH FNRS/N KSA1-739
Group No: 502-0337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1892077 | 1 FILM-IDENTIFICATION (LIFT, FLOAT, LOWER) | 1 | |
| 1892078 | 2 FILM-IDENTIFICATION (DUMP, TILT BACK) | 1 | |
| 1892079 | 3 FILM-INSTRUCTION (MAINTENANCE) | 1 | |
| 2015563 | 4 FILM-IDENTIFICATION (AUXILIARY HYDRAULIC) | 1 | |
| 2286089 | 5 PLUG (ROCKER SWITCH) | 3 | |
| 2756530 | 6 FILM-IDENTIFICATION (HORN, TRANSMISSION DIRECTION) | 1 | |
| 3246610 | 7 SWITCH AS-ROCKER (FORWARD, NEUTRAL, REVERSE) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 2813121 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 2813122 | RECEPTACLE AS-CONNECTOR | 1 | |
| 3492600 | 8 ADJUSTER GP-CONTROL | 1 | |
| 1313987 | SCREW (M4X0.7X12-MM) | 2 | |
| 3492593 | HANDLE | 1 | |
| 3616015 | 9 CONTROL GP-HANDLE | 1 | |
| 3677476 | 10 COVER | 1 | |
| 3677477 | 11 COVER | 1 | |
| 3677479 | 12 BRACKET AS | 1 | |
| 4439873 | 13 CUSHION AS | 1 | |
| 2057048 | INSERT-THREADED (M6X1-X14.73-MM) | 4 | |
| 5020277 | 14 WIRING GP-CONTROL | 1 | |
| 5C2890 | 15 NUT (M6X1-THD) | 3 | |
| 5C7261 | 16 NUT (M8X1.25-THD) | 3 | |
| 8R3695 | 17 GROMMET | 4 | |
| 8T4138 | 18 BOLT (M6X1X20-MM) | 3 | |
| 8T4205 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X2045 | 21 SCREW-TRUSS HEAD (M6X1X20-MM) | 16 |
