System And Components
236-8997 LINES GP-HYDRAULICS/N A6D2325-2442
Group No: 236-8997 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V1878 | 1 HOSE | 1 | |
| 8T6907 | 2 VALVE-BALL | 1 | |
| 1488424 | 3 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 1488440 | 4 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C0569 | TEE-O-RING | 1 | |
| 1645567 | 5 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1882008 | 6 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T7970 | ELBOW | 1 | |
| 1987651 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2582829 | 8 BREATHER (HYDRAULIC TANK) | 1 | |
| 2416209 | 9 UNION AS-CROSS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1175208 | CROSS | 1 | |
| 2433720 | 10 CLAMP | 2 | |
| 2434186 | 11 HOSE AS | 1 | |
| 2434187 | 12 HOSE AS | 1 | |
| 2434566 | 13 TUBE AS | 1 | |
| 2434623 | 14 HOSE AS | 1 | |
| 2434624 | 15 HOSE AS | 1 | |
| 2434625 | 16 HOSE AS | 1 | |
| 2434626 | 17 HOSE AS | 1 | |
| 2434692 | 18 HOSE AS | 1 | |
| 2434786 | 19 TUBE AS | 1 | |
| 2436897 | 20 BRACKET AS | 1 | |
| 2455943 | 21 VALVE GP-DRAIN (ECOLOGY, HYDRAULIC) | 1 | |
| 2461133 | 22 HOSE AS | 1 | |
| 2463371 | 23 TUBE AS | 1 | |
| 2492334 | 24 FILTER GP-OIL (ULTRA HIGH EFFICIENCY)(HYDRAULIC CASE DRAIN) | 1 | |
| 2957007 | 25 HOSE AS | 1 | |
| 2609189 | 26 ELBOW AS-SWIVEL | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1248333 | ELBOW | 1 | |
| 2557790 | 27 HOSE AS | 1 | |
| 3373953 | 28 GUARD AS | 1 | |
| 2707147 | 29 BRACKET AS | 1 | |
| 3298276 | 30 HOSE AS | 1 | |
| 2733959 | 31 TUBE AS | 1 | |
| 2745871 | 32 HOSE AS | 1 | |
| 2758880 | 33 FLANGE | 1 | |
| 2262256 | 34 HOSE AS | 1 | |
| 1488327 | 35 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 36 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 8T4140 | 37 BOLT (M16X2X60-MM) | 2 | |
| 8T4195 | 38 BOLT (M10X1.5X30-MM) | 1 | |
| 1488366 | 39 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8987 | ELBOW | 1 | |
| 1488378 | 40 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488380 | 41 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8988 | ELBOW | 1 | |
| 8T7934 | 42 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 1488455 | 43 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1503068 | 44 UNION AS | 2 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9649 | ELBOW | 1 | |
| 1536230 | 45 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T9386 | CONNECTOR | 1 | |
| 1536248 | 46 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 1984780 | 47 WASHER-HARD (17.5X32X8-MM THK) | 2 | |
| 1536237 | 48 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P3704 | 49 SEAL-RECTANGULAR | 2 | |
| 1P4579 | 50 FLANGE-HALF | 6 | |
| 1P5767 | 51 FLANGE-HALF | 4 | |
| 1S0994 | 52 CLIP (LOOP) | 2 | |
| 2257657 | 53 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9X2091 | ELBOW (SWIVEL) | 1 | |
| 2H6338 | 54 SEAL-O-RING | 2 | |
| 2P1293 | 55 LOCKNUT (1-3/16-12-THD) | 1 | |
| 2006345 | 56 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 3P2404 | 57 CLIP | 2 | |
| 4D7388 | 58 CLIP | 1 | |
| 4J0524 | 59 SEAL-O-RING | 4 | |
| 2042281 | 60 STRAP-CABLE | 4 | |
| 5P1076 | 61 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6D4244 | 62 CLIP (LOOP) | 1 | |
| 6D4246 | 63 CLIP (LOOP) | 1 | |
| 6V0852 | 64 CAP-DUST | 1 | |
| 6V1875 | 65 GROMMET | 1 | |
| 6V1889 | 66 CLIP (LOOP) | 2 | |
| 6V9168 | 67 NUT (11/16-16-THD) | 1 | |
| 6V9169 | 68 NUT (13/16-16-THD) | 1 | |
| 7K1401 | 69 CLIP | 1 | |
| 7K1402 | 70 BRACKET | 1 | |
| 7X0591 | 71 WASHER-HARD (17X29X3-MM THK) | 4 | |
| 7X2543 | 72 BOLT (M10X1.5X120-MM) | 4 | |
| 8T4121 | 73 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 74 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 75 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4183 | 76 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4184 | 77 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4192 | 78 BOLT (M12X1.75X25-MM) | 3 | |
| 8T4193 | 79 BOLT (M16X2X50-MM) | 4 | |
| 8T4194 | 80 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 81 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 8T4956 | 82 BOLT (M12X1.75X35-MM) | 2 | |
| 8T4985 | 83 CLAMP-HOSE | 2 | |
| 9X8257 | 84 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 3J1907 | 85 SEAL-O-RING | 1 |
