System And Components
241-0639 BATTERY & WIRING GPS/N N1A1-1352
Group No: 241-0639
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 7 | |
| 5I8304 | 3 ROD | 1 | |
| 6W6005 | 4 HOLD-DOWN-BATTERY | 1 | |
| 7N0718 | 5 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 1160080 | 6 CABLE AS (JUMPER) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(31-CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2461696 | 7 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(71-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2461697 | 8 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(59-CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8S3020 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9X5699 | BOOT | 1 | |
| 2461698 | 9 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0761 | CABLE (00-GA, RED)(173-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 2 | |
| 2461715 | 10 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0747 | CABLE (00-GA, BLACK)(66-CM) | ||
| 2479989 | 11 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(48-CM) | ||
| 8S3020 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 2167790 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 2480072 | 12 CABLE AS | 1 | |
| 1P0810 | TAPE-ELECTRICAL | 1 | |
| 8C3056 | CABLE (2-GA, RED)(307-CM) | ||
| 8T8827 | BOOT (RED) | 1 | |
| 6V9023 | TUBE-HEAT SHRINK (12.7-MM DIA)(3-CM) | ||
| 0301712 | TERMINAL-RING (2-GA, 1/4-IN SCREW) | 2 | |
| 2314476 | TERMINAL AS | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2639574 | 13 BATTERY AS (12-VOLT, MAINTENANCE FREE) | 2 | |
| 2726537 | 14 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 0338248 | 15 CLIP (LOOP) | 12 | |
| 1327551 | 16 SPACER (11X19X6-MM THK) | 3 | |
| 1339379 | 17 GROMMET | 2 | |
| 2057299 | 18 CLIP (LOOP) | 7 | |
| 2W7940 | 19 BRACKET | 1 | |
| 4D9517 | 20 CLIP | 1 | |
| 5C7261 | 21 NUT (M8X1.25-THD) | 1 | |
| 5G6505 | 22 WASHER (25X38X14-MM THK) | 2 | |
| 6V8188 | 23 NUT (1/2-13-THD) | 4 | |
| 8C6358 | 24 BLOCK AS-JUNCTION (BATTERY) | 1 | |
| 1D5117 | NUT-JAM (1/2-13-THD) | 3 | |
| 8T3519 | BOLT-BRONZE (1/2-13X2-IN) | 3 | |
| 8T0389 | 25 LOCKNUT (M10X1.5-THD) | 1 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4133 | 27 NUT (M10X1.5-THD) | 5 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 29 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4189 | 30 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4192 | 31 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4196 | 32 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4226 | 35 WASHER-PLATED (10.5X45X3-MM THK) | 1 | |
| 8T4244 | 36 NUT (M12X1.75-THD) | 1 |
