System And Components
306-5349 WIRING GP-CHASSIS -VARIABLE PITCH FANS/N M1G1-UP
Group No: 306-5349
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 24 | |
| 3065352 | 2 HARNESS AS-CHASSIS (VARIABLE PITCH FAN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1148843 | SLEEVE-PLASTIC (80-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 7 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 2L8054 | TERMINAL-RING (6-GA, 1/2-IN SCREW) | 1 | |
| 2L8061 | TERMINAL-RING (8-GA, 1/2-IN SCREW) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 3523964 | 3 CLIP (LADDER) | 1 | |
| 3220931 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2697678 | 6 CLIP | 1 | |
| 1325789 | 7 CLIP (LADDER) | 1 | |
| 8T4137 | 8 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 3S2093 | 10 STRAP-CABLE | 5 |
