System And Components
236-8988 LINES GP-WATER -RADIATORS/N FMW23-UP
Group No: 236-8988
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1262 | 1 HOSE (11.5-CM EACH) | ||
| 6S8620 | 2 CLAMP-HOSE | 2 | |
| 7K1181 | 3 STRAP-CABLE | 1 | |
| 7X1443 | 4 PROTECTOR | 8 | |
| 8F8151 | 5 VALVE-SHUTOFF (RADIATOR DRAIN) | 1 | |
| 8T4983 | 6 CLAMP-HOSE | 2 | |
| 9Y9236 | 7 GAUGE-SIGHT (COOLANT LEVEL) | 1 | |
| 1503024 | 8 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 2418506 | 9 TUBE | 1 | |
| 2601818 | 10 TUBE AS | 1 | |
| 2681497 | 11 ELBOW | 1 | |
| 2684045 | 12 CONNECTOR | 1 | |
| 3122014 | 13 TANK GP-RADIATOR TOP | 1 | |
| 1241479 | 14 CLIP (LOOP) | 1 | |
| 1697397 | 15 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 3243210 | 16 CLAMP | 8 | |
| 3D2824 | 17 SEAL-O-RING | 1 | |
| 3J7354 | 18 SEAL-O-RING | 2 | |
| 5D1026 | 19 CLAMP-BAND | 1 | |
| 5P1230 | 20 CONNECTOR | 1 | |
| 6V1355 | 21 ELBOW | 1 | |
| 7D7233 | 22 CLIP (LOOP) | 2 | |
| 7M8485 | 23 SEAL-O-RING | 1 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 2 | |
| 5P1251 | 29 HOSE (110-CM) | ||
| 5P0767 | 30 HOSE (69-CM) | ||
| 5P1442 | 31 HOSE (28-CM) | ||
| 5P6442 | 32 HOSE (67-CM) | ||
| 7Y1976 | 33 HOSE-WATER (285-CM) | ||
| 1P4278 | 34 CLAMP-HOSE | 2 |
