System And Components
392-7093 CONTROL & MTG GP-ELHYDS/N SA81-10249
Group No: 392-7093
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2538798 | 1 KNOB (ARMREST ADJUSTMENT) | 1 | |
| 2809440 | 2 CUSHION AS | 1 | |
| 2838171 | 3 BRACKET | 1 | |
| 2855521 | 4 BRACKET AS | 1 | |
| 2858015 | 5 FILM-IDENTIFICATION (JOYSTICK CONTROL, 2-FUNCTION) | 1 | |
| 3053458 | 6 CUSHION AS | 1 | |
| 4588673 | 7 CONTROL GP-HANDLE (2-VALVE) | 1 | |
| 3379106 | 8 COVER | 1 | |
| 4237784 | 9 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3615015 | 10 SUPPORT GP-HYDRAULIC CONTROL | 1 | |
| 3927082 | 11 COVER AS | 1 | |
| 4227815 | 12 WIRING GP-CONTROL (JOYSTICK) | 1 | |
| 1126646 | 13 LOCKNUT (M6X1-THD) | 4 | |
| 5C2890 | 14 NUT (M6X1-THD) | 3 | |
| 8T4897 | 15 WASHER (10.2X35X6-MM THK) | 1 | |
| 8R3695 | 16 GROMMET | 4 | |
| 8T4197 | 17 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 3 | |
| 9X2043 | 20 SCREW-TRUSS HEAD (M6X1X14-MM) | 10 | |
| 8T4205 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 3 |
