Assembly
100%

524-6866 BLADE GP-REVERSIBLES/N B8P1-UP

Group No: 524-6866
Part NumberPart NameQty
53695571 BLADE AS (LH)1
4K0367NUT-FULL (5/8-11-THD)11
3B8489FITTING-GREASE (1/8-27 PTF)4
4F3654BOLT-PLOW (5/8-11X2-IN)11
5289447EDGE-CUTTING1
53695582 BLADE AS (RH)1
4K0367NUT-FULL (5/8-11-THD)11
4F3654BOLT-PLOW (5/8-11X2-IN)11
5289447EDGE-CUTTING1
53027973 FRAME AS-BLADE1
52968534 CYLINDER GP-BLADE2
52894345 PIN AS1
52894356 PIN4
52894367 SHOE AS2
1D4616BOLT (3/4-10X6-IN)1
3E9862LOCKNUT (3/4-10-THD)1
52894378 SPACER1
2K80789 PIN-SPRING1
8S908910 BOLT (1/2-13X4.5-IN)4
0S158711 BOLT (1/2-13X1.75-IN)1
3B450812 LOCKWASHER1
5P824513 WASHER-HARD (13.5X25.5X3-MM THK)1
9X094114 LOCKNUT (1/2-13-THD)4
5289438KIT-HYDRAULIC LINES1
5296854KIT-SEAL (HYDRAULIC CYLINDER)1
