System And Components
346-6391 SENSOR & MTG GP-TILT POSITIONS/N R4A1-UP
Group No: 346-6391
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2494134 | 1 PLATE | 1 | |
| 2662337 | 2 SENSOR GP-POSITION (ROTARY) | 1 | |
| 3560956 | 3 PLATE | 1 | |
| 3582174 | 4 ROD AS | 1 | |
| 1608503 | NUT (M10X1.5-THD) | 1 | |
| 3613244 | 5 BRACKET AS | 1 | |
| 3623153 | 6 PLATE AS | 1 | |
| 3W3165 | SPACER (10X18X6-MM THK) | 15 | |
| 1305300 | 7 CLIP | 1 | |
| 1327551 | 8 SPACER (11X19X6-MM THK) | 2 | |
| 4D7794 | 9 CLIP | 1 | |
| 5C7261 | 10 NUT (M8X1.25-THD) | 5 | |
| 6V7357 | 11 BOLT (M6X1X25-MM) | 2 | |
| 7X0818 | 12 BOLT (M8X1.25X45-MM) | 5 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4185 | 17 BOLT (M10X1.5X50-MM) | 6 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 2 |
