313-9723 LIGHTING GP-FLOOD & SIGNALS/N Z4W1-UP

Group No: 313-9723
Part NumberPart NameQty
7K11811 STRAP-CABLE2
24632902 PLATE AS2
8T4935BOSS-WELD (M10X1.5X45-MM)1
25271653 LAMP GP-SIGNAL (24-VOLT)2
8T8729PIN-CONNECTOR (16-GA TO 20-GA)4
34434554 LAMP GP-HEAD & SIGNAL (24-VOLT)(RH)1
34434565 LAMP GP-HEAD & SIGNAL (24-VOLT)(LH)1
35274846 HARNESS AS-LIGHTING2
8T8737PLUG-SEAL2
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)10
1261768SOCKET-CONNECTOR (14-GA TO 16-GA)10
1552274KIT-CONNECTING PLUG (6-PIN)1
2305010PLUG AS-CONNECTOR (6-PIN)1
2647032SEAL-CONNECTOR1
35287417 BRACKET AS1
35287458 BRACKET AS1
28930389 GROMMET2
130530010 CLIP2
1W958911 NUT (M10X1.5-THD)2
5C289012 NUT (M6X1-THD)6
8T412113 WASHER-HARD (11X21X2.5-MM THK)2
368508114 BOLT (M10X1.5X25-MM)8
8T413715 BOLT (M10X1.5X20-MM)2
9X203816 WASHER (7X19X2-MM THK)8
9X204417 SCREW-TRUSS HEAD (M6X1X16-MM)8
9X825618 WASHER (6.6X12X2-MM THK)6
9X204519 SCREW-TRUSS HEAD (M6X1X20-MM)8
9X734520 GROMMET2
219648521 LAMP GP-FLOOD (24-VOLT)(LH)1
219648521A LAMP GP-FLOOD (24-VOLT)(RH)1
365877322 PLATE2
344119923 WASHER-HARD (11X21X2.5-MM THK)8
1028804KIT-RECEPTACLE (4-PIN)
