System And Components
454-9753 ACTUATOR GP-POWERS/N Z4W349-UP
Group No: 454-9753
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4226220 | 1 MOUNT AS | 1 | |
| 1224233 | 2 WIPER | 1 | |
| 4511546 | 3 POST AS | 1 | |
| 3563101 | 4 POWERHEAD AS | 1 | |
| 1794324 | 5 LOCKNUT (M5X0.8-THD) | 2 | |
| 1682166 | 6 GASKET-MOTOR | 1 | |
| 2036473 | 7 GASKET | 1 | |
| 3563102 | 8 MOTOR AS-ELECTRIC (HOOD TILT) | 1 | |
| 8N1540 | PIN-CONNECTOR (12-GA TO 14-GA) | 1 | |
| 8N1541 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 1 | |
| 1297163 | PLUG AS-CONNECTOR (1-PIN) | 1 | |
| 1297164 | RECEPTACLE AS-CONNECTOR (1-PIN) | 1 | |
| 4254646 | 9 ROD END | 1 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 3445675 | 11 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 2 |
