System And Components
351-7640 CONTROL GP-FOOT BRAKES/N Z4W1-UP
Group No: 351-7640
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1056117 | 1 SWITCH AS-LIMIT (STOP LIGHT) | 1 | |
| 1461892 | 2 HARNESS AS-BRAKE (STOP LIGHT) | 1 | |
| 4E8951 | GROMMET AS | 1 | |
| 8C8514 | SCREW-MACHINE (8-32X0.375-IN) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 5P2957 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 5P5602 | TERMINAL-BLADE (18-GA TO 22-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2002217 | 3 COVER | 1 | |
| 2002218 | 4 BRACKET AS-ADJUSTABLE SWITCH | 1 | |
| 2002219 | 5 BOLT (M5X0.8X25-MM) | 8 | |
| 2002220 | 6 SEAL | 1 | |
| 2661466 | 7 SENSOR GP-POSITION (ROTARY) | 1 | |
| 1253295 | 8 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 8T2899 | 9 SCREW-MACHINE (M2.5X0.45X6-MM) | 2 |
