348-2712 WIRING GP-CABS/N FER156-UP

Group No: 348-2712

Part Number	Part Name	Qty
6V3987	1 SEAL (0.1-M)
6I1418	2 SPACER (8.2X12.7X28.7-MM THK)	11
8T9655	3 MOUNT-ISOLATION	22
8X9618	4 STRAP AS-GROUND	2
1058034	5 SWITCH AS-LIMIT (DOOR, LH)	1
1076032	6 LAMP AS-DOME (24-VOLT)	2
2591286	LAMP (24-VOLT, 10-WATT)	1
1138490	7 FUSE (10-AMPERE)	26
1138491	8 FUSE (15-AMPERE)	17
1138492	9 FUSE (20-AMPERE)	2
1239694	10 HORN	1
1284249	11 LOCKWASHER	1
1321829	12 ALARM GP (24-VOLT)(ACTION)	1
1412759	13 FUSE (5-AMPERE)	2
1809900	15 CAP AS	2
5P7958	SLEEVE-CABLE SPLICE	1
8C6354	CAP-RECEPTACLE (ET CONNECTOR)	1
1799392	LANYARD	1
1878675	16 GASKET	1
1912276	17 SCREW-TRUSS HEAD (M5X0.8X20-MM)	2
2039007	18 NUT (1-1/2-18-THD)	2
2284982	19 RESISTOR AS	1
1028802	KIT-RECEPTACLE (2-PIN)	1
6T3610	RESISTOR	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
2418368	20 SWITCH GP-MAGNETIC (24-VOLT)(LOW CURRENT MODULE RELAY)	1
2418368	20A SWITCH GP-MAGNETIC (24-VOLT)(MAIN POWER RELAY)	1
2421555	21 PULLER-FUSE	1
2482841	22 RELAY AS (24-VOLT)	18
2552752	23 SWITCH GP-START (IGNITION)	1
2702679	24 LOCKWASHER	2
2727239	25 BLOCK AS	1
2802709	26 CIRCUIT BREAKER AS (15-AMPERE, MANUAL RESET)(WINDOW WIPER)	1
2802709	26A CIRCUIT BREAKER AS (15-AMPERE, MANUAL RESET)(VENTILATION FAN)	1
2802709	26B CIRCUIT BREAKER AS (15-AMPERE, MANUAL RESET)(CRANKCASE GUARD ACTUATOR)	1
2802710	27 CIRCUIT BREAKER AS (20-AMPERE, MANUAL RESET)(HOOD TILT ACTUATOR)	1
2843623	28 SWITCH AS-ROCKER (24-VOLT)(HYDRAULIC LOCKOUT)	1
2843665	29 SWITCH AS-ROCKER (24-VOLT)(AIR CONDITIONER, HEATER CONT)	1
2888155	30 PANEL AS (AIR CONDITIONER, HEATER CONT)	1
2717312	KNOB	2
2888554	31 PANEL AS (WINDOW WIPER CONTROLS)	1
2717312	KNOB	2
2902968	32 HARNESS AS-LIGHTING	1
2909704	33 SWITCH AS-ROCKER (WINDOW WIPER CONTROLS)	1
4603173	34 MODULE GP-KEYPAD (8-BUTTON)	1
8F1326	WASHER (4.2X9.5X0.8-MM THK)	2
8T2659	LOCKNUT (M4X0.7-THD)	2
4603188	35 MODULE GP-KEYPAD (16-BUTTON)	1
8F1326	WASHER (4.2X9.5X0.8-MM THK)	4
8T2659	LOCKNUT (M4X0.7-THD)	4
2934465	36 MODULE GP-RELAY DRIVER (RELAY DRIVER MODULE)	1
2995744	MODULE GP-RELAY DRIVER	1
7X6315	STRAP AS-GROUND	1
1344126	WASHER (4.52X8.28X0.76-MM THK)	1
1842472	SCREW-PAN HEAD (8-32X0.375-IN)	1
3045687	37 CONTROL GP-UNPROGRAMMED (IMPLEMENT)	1
3045687	37A CONTROL GP-UNPROGRAMMED (TRANSMISSION)	1
3917036	40 CONTROL GP-UNPRGMED MONITOR	1
3675213	41 SWITCH AS-ROCKER (24-VOLT)	1
3355365	42 SOCKET-AUXILIARY POWER (12-VOLT)	3
3407161	43 CONVERTER-POWER (24-VOLT TO 12-VOLT)	1
3461059	44 BRACKET AS	1
3461060	45 BRACKET AS	1
3461064	46 GASKET	1
3905514	47 FILM-IDENTIFICATION (FUSE PANEL, UPPER)	1
3905516	48 FILM-IDENTIFICATION (FUSE PANEL, LOWER)	1
3461068	49 BAR-BUS	1
3520381	51 FLASHER AS (12/24-VOLT)(TURN SIGNAL)	1
3521695	52 DISPLAY GP-CAMERA	1
3620138	53 PLATE	1
0964833	54 BOLT-SOCKET HEAD (M5X0.8X20-MM)	4
1272170	55 SCREW-TRUSS HEAD (M8X1.25X20-MM)	1
1305300	56 CLIP	4
1342540	57 RECEPTACLE AS-CONNECTOR (3-PIN)	1
1388454	58 SCREW-TRUSS HEAD (M4X0.7X10-MM)	2
1748131	59 SCREW-TRUSS HEAD (M4X0.7X12-MM)	3
2110052	61 NUT (1-11/16-18-THD)	1
7I2272	62 BOLT (M5X0.8X12-MM)	8
2747409	63 SCREW-TRUSS HEAD (M8X1.25X45-MM)	11
3S2093	64 STRAP-CABLE	7
7K1181	65 STRAP-CABLE	44
8T0328	66 WASHER-HARD (5.5X10X1-MM THK)	12
8T4121	67 WASHER-HARD (11X21X2.5-MM THK)	11
8T4137	68 BOLT (M10X1.5X20-MM)	11
8T4179	69 BOLT (M12X1.75X20-MM)	2
8T4223	71 WASHER-HARD (13.5X25.5X3-MM THK)	2
9N0869	73 WASHER-HARD (8.8X25.5X2-MM THK)	14
9X1046	74 SCREW (M4X0.7X18-MM)	4
9X2041	75 SCREW-TRUSS HEAD (M10X1.5X20-MM)	1
9X2044	76 SCREW-TRUSS HEAD (M6X1X16-MM)	24
9X2045	77 SCREW-TRUSS HEAD (M6X1X20-MM)	4
4371967	78 WIRING GP-CAB	1
3391103	79 WASHER (6.6X35X1.5-MM THK)	3
2943313	80 CLIP (LADDER)	1
1178929	81 WASHER (6.6X22X2-MM THK)	1
0996418	82 NUT (M6X1-THD)	3
