System And Components
360-0306 VALVE & LINES GP-STEERING NEUTS/N HE81-UP
Group No: 360-0306
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 6 | |
| 1466581 | 2 BOLT-FLAT HEAD (M12X1.75X72-MM) | 2 | |
| 1925017 | 3 BRACKET AS | 1 | |
| 2501417 | 4 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 2 | |
| 6V8397 | SEAL-O-RING | 4 | |
| 2501416 | ELBOW | 2 | |
| 2501467 | 5 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7I8663 | CONNECTOR | 1 | |
| 2945076 | 6 PLATE AS | 1 | |
| 2965662 | 7 VALVE GP-STEERING NEUTRALIZER (HMU) | 2 | |
| 3095127 | 8 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1523411 | ELBOW | 1 | |
| 3600370 | 10 HOSE | 1 | |
| 3600371 | 11 ELBOW | 1 | |
| 3600374 | 12 TUBE AS | 2 | |
| 3600377 | 13 BRACKET AS | 1 | |
| 3600384 | 14 HOSE AS | 1 | |
| 4413485 | 15 VALVE GP-STEERING | 1 | |
| 3849453 | 16 BRACKET AS | 1 | |
| 3849478 | 17 HOSE AS | 1 | |
| 3849532 | 19 HOSE AS | 2 | |
| 3849533 | 20 HOSE AS | 2 | |
| 3916966 | 21 HOSE AS | 1 | |
| 3916967 | 22 HOSE AS | 1 | |
| 3916969 | 23 HOSE AS | 1 | |
| 3916970 | 24 HOSE AS | 1 | |
| 4157499 | 25 HOSE AS | 1 | |
| 4157500 | 26 HOSE AS | 1 | |
| 4270343 | 27 BRACKET | 2 | |
| 4505493 | 28 HOSE AS | 1 | |
| 4505494 | 29 HOSE AS | 1 | |
| 4505499 | 30 TUBE AS | 1 | |
| 4505500 | 31 HOSE AS | 1 | |
| 4527174 | 32 HOSE AS | 1 | |
| 1488315 | 33 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488336 | 34 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488340 | 35 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488351 | 36 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488353 | 37 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488363 | 38 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488365 | 39 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488371 | 40 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1504048 | 42 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1553502 | 43 ADAPTER AS | 1 | |
| 3E7403 | ADAPTER | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1647908 | 44 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T7546 | ELBOW | 1 | |
| 1654934 | 45 PLUG AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9508 | PLUG (11/16-16-THD) | 1 | |
| 1984777 | 46 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2042281 | 47 STRAP-CABLE | 1 | |
| 2062423 | 48 SADDLE-MOUNTING | 3 | |
| 2681646 | 49 UNION AS-CROSS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 2681645 | CROSS | 1 | |
| 2971546 | 50 CLIP | 1 | |
| 3293356 | 51 NUT (M12X1.75-THD) | 2 | |
| 3445675 | 52 NUT (M10X1.5-THD) | 4 | |
| 3G8054 | 53 CLIP (TAB) | 2 | |
| 3G8057 | 54 CLIP (SLOT) | 2 | |
| 3P5903 | 55 CLIP (TAB) | 2 | |
| 3P5904 | 56 CLIP (SLOT) | 2 | |
| 4D7733 | 57 CLIP (LOOP) | 2 | |
| 4J0520 | 58 SEAL-O-RING | 2 | |
| 4J0528 | 59 SEAL-O-RING | 1 | |
| 6V0974 | 60 GROMMET | 2 | |
| 7J9108 | 62 SEAL-O-RING | 2 | |
| 7X2543 | 63 BOLT (M10X1.5X120-MM) | 1 | |
| 8C3206 | 64 FLANGE-HALF | 2 | |
| 8M2773 | 65 CLIP (LOOP) | 5 | |
| 8T4121 | 66 WASHER-HARD (11X21X2.5-MM THK) | 37 | |
| 8T4136 | 67 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 68 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4176 | 69 BOLT (M12X1.75X90-MM) | 1 | |
| 8T4186 | 70 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 71 BOLT (M10X1.5X30-MM) | 7 | |
| 8T4196 | 72 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4223 | 73 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4910 | 74 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4984 | 75 CLAMP-HOSE | 2 | |
| 8T5436 | 76 BOLT (M10X1.5X130-MM) | 2 | |
| 8T6466 | 77 BOLT (M10X1.5X60-MM) | 4 |
