System And Components
360-2223 SENSOR & MTG GP-TILT POSITIONS/N LXX20201-UP
Group No: 360-2223
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1233202 | 1 STRAP-CABLE | 1 | |
| 1686514 | 2 SPACER (10.74X17.14X50.8-MM THK) | 1 | |
| 2494127 | 3 BRACKET AS | 1 | |
| 2494134 | 4 PLATE | 1 | |
| 2662337 | 5 SENSOR GP-POSITION (ROTARY) | 1 | |
| 2697250 | 6 PLATE | 1 | |
| 3535195 | 7 ARM-BAIL | 1 | |
| 3535200 | 8 COVER | 1 | |
| 1364184 | 9 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 5 | |
| 2802747 | 10 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 1 | |
| 4D7794 | 11 CLIP | 1 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T4971 | 17 BOLT (M6X1X30-MM) | 2 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 2 |
