System And Components
448-0856 VALVE & LINES GP -WITH HEAT INSULATIONS/N FRS1-UP
Group No: 448-0856
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1121817 | 1 VALVE-BALL | 1 | |
| 1504027 | 2 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2610424 | 3 PLATE | 1 | |
| 1488336 | 4 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488378 | 5 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 4516854 | 6 HOSE AS (WITH HEAT INSULATION) | 1 | |
| 4501055 | HOSE AS | 1 | |
| 2Q0604 | INSULATION (63-CM) | ||
| 3709488 | STRAP-CABLE | 2 | |
| 4516855 | 7 HOSE AS (WITH HEAT INSULATION) | 1 | |
| 4239948 | HOSE AS | 1 | |
| 2Q0604 | INSULATION (95-CM) | ||
| 3709488 | STRAP-CABLE | 2 | |
| 0966166 | 8 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1214405 | 9 BOLT (M4X0.7X12-MM) | 4 | |
| 1488367 | 10 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488407 | 11 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1646874 | 12 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 3445675 | 13 NUT (M10X1.5-THD) | 1 | |
| 3709488 | 14 STRAP-CABLE | 2 | |
| 5P7462 | 15 CLIP (SLOT) | 1 | |
| 5P7463 | 16 CLIP (TAB) | 1 | |
| 6V0683 | 17 GROMMET | 1 | |
| 7X7729 | 18 WASHER (11X25X3-MM THK) | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 2 |
