System And Components
433-9298 SUPPORT GP-RADIATORS/N LSJ1-UP
Group No: 433-9298
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1384 | 1 BUMPER-CONICAL | 2 | |
| 1125344 | 2 LATCH AS-DOOR | 1 | |
| 4339297 | 3 SUPPORT GP-RADIATOR (COOLING) | 1 | |
| 4365945 | 4 STRIKER | 1 | |
| 3445675 | 6 NUT (M10X1.5-THD) | 13 | |
| 5C7261 | 7 NUT (M8X1.25-THD) | 2 | |
| 5V8780 | 8 KNOB | 1 | |
| 6V7744 | 9 LOCKNUT (M10X1.5-THD) | 8 | |
| 7X0474 | 10 BOLT (M10X1.5X220-MM) | 8 | |
| 7X0515 | 11 WASHER-HARD (17X35X5-MM THK) | 8 | |
| 7X0579 | 12 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 7X0632 | 13 WASHER-HARD (11X36X6-MM THK) | 1 | |
| 7X2533 | 14 BOLT (M6X1X35-MM) | 4 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 57 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4186 | 17 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 22 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4226 | 20 WASHER-PLATED (10.5X45X3-MM THK) | 4 | |
| 8T7338 | 21 BOLT (M16X2X45-MM) | 8 | |
| 8T7547 | 22 BOLT (M8X1.25X30-MM) | 4 | |
| 9X8256 | 23 WASHER (6.6X12X2-MM THK) | 4 | |
| 1906616 | 24 SEAL (36-CM) | ||
| 1906616 | 24A SEAL (26-CM) | ||
| 3563181 | 25 SEAL (104-CM EACH) | ||
| 7X7877 | 26 STRIP-EDGE (6-CM) | ||
| 7X7877 | 26A STRIP-EDGE (5-CM EACH) | ||
| 7X7877 | 26B STRIP-EDGE (3-CM) |
