System And Components
547-7282 GEAR GP-BEVEL & PINIONS/N SGW1-UP
Group No: 547-7282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1262522 | 1 CONE-BEARING | 1 | |
| 1P3934 | 2 CUP-BEARING | 1 | |
| 2952342 | 3 NUT-ADJUSTING | 1 | |
| 2952409 | 4 BOLT (M20X2.5X140-MM) | 16 | |
| 2973211 | 5 LOCK-BEARING | 2 | |
| 3616092 | 6 SET-BEVEL GEAR | 1 | |
| 3688010 | 7 NUT-ADJUSTING | 1 | |
| 4468185 | 8 YOKE AS | 1 | |
| 2H3931 | SEAL-O-RING | 1 | |
| 4270285 | RING-RETAINING | 1 | |
| 4799993 | CAP-DUST | 1 | |
| 5475487 | 9 BEARING-TAPER | 1 | |
| 5475488 | 10 BEARING-TAPER | 1 | |
| 5475489 | 11 BEARING-TAPER | 1 | |
| 6V8210 | 12 BOLT (M8X1.25X16-MM) | 2 | |
| 6W4749 | 13 WASHER (75.5X106X5-MM THK) | 1 | |
| 6W4750 | 14 NUT-STAKE (LOCK) | 1 | |
| 9X2619 | 15 PIN-SPRING | 4 | |
| 9X2620 | 16 PIN-SPRING | 4 |
