System And Components
577-7067 PUMP GP-PISTON -HYDRAULIC FANS/N SGW1-UP
Group No: 577-7067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2735073 | 1 ROTATING GP-PUMP (HYDRAULIC FAN) | 1 | |
| 1660344 | 2 SEAL-SHAFT | 1 | |
| 1749994 | 3 PISTON-CONTROL | 1 | |
| 2747452 | 4 LINK-CONTROL | 1 | |
| 3128769 | 5 SWASHPLATE | 1 | |
| 1982617 | 6 SHAFT | 1 | |
| 1985351 | 7 PLUG | 1 | |
| 1886303 | 8 SPRING | 1 | |
| 1559133 | 9 KEY | 1 | |
| 1481238 | 10 SHIM (3-MM THK) | 1 | |
| 1683504 | 11 SEAL | 1 | |
| 2807870 | 12 GASKET | 2 | |
| 9X8979 | 13 DOWEL | 1 | |
| 3601413 | 14 VALVE GP-PUMP CONTROL (FLOW COMPENSATOR) | 1 | |
| 9X2537 | 15 BOLT-SOCKET HEAD (M6X1X70-MM) | 4 | |
| 1850242 | 16 PLATE | 1 | |
| 8C3110 | 17 RING-RETAINING | 1 | |
| 6V4636 | 18 CUP-BEARING | 1 | |
| 2038609 | 19 CUP-BEARING | 1 | |
| 1687869 | 20 BEARING-CRADLE | 2 | |
| 1053035 | 21 CONE-BEARING | 1 | |
| 6V4635 | 22 CONE-BEARING | 1 | |
| 1593040 | 23 BOLT-SOCKET HEAD (M12X1.5X45-MM) | 4 | |
| 1066547 | 24 SEAL-O-RING | 1 | |
| 8T7525 | 25 SEAL-O-RING | 1 | |
| 4793085 | 26 VALVE GP-SOLENOID (24-VOLT)(HYDRAULIC FAN) | 1 | |
| 4531743 | COIL AS | 1 | |
| 2173875 | SEAL-O-RING | 1 | |
| 2477054 | NUT AS (KIT) | 1 | |
| 1367227 | SEAL-O-RING | 1 | |
| 3427206 | KIT-SEAL | 1 | |
| 4695750 | 27 PLATE | 1 | |
| 9S8002 | 28 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 29 SEAL-O-RING | 1 |
