System And Components
495-0873 CONTROL & MTG GP-ELHYDS/N LSE1-20200
Group No: 495-0873
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2538798 | 1 KNOB | 1 | |
| 2809440 | 2 CUSHION AS | 1 | |
| 2838171 | 3 BRACKET | 1 | |
| 2855521 | 4 BRACKET AS | 1 | |
| 2858016 | 5 FILM-IDENTIFICATION (JOYSTICK CONTROL, 3-FUNCTION) | 1 | |
| 3053458 | 6 CUSHION AS | 1 | |
| 3379106 | 7 COVER | 1 | |
| 3927082 | 8 COVER AS | 1 | |
| 4237784 | 9 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4588670 | 10 CONTROL GP-JOYSTICK (3-VALVE) | 1 | |
| 4956227 | 11 WIRING GP-CONTROL (JOYSTICK) | 1 | |
| 1126646 | 12 LOCKNUT (M6X1-THD) | 4 | |
| 5C2890 | 13 NUT (M6X1-THD) | 3 | |
| 8R3695 | 14 GROMMET | 4 | |
| 8T4197 | 15 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4205 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4897 | 18 WASHER (10.2X35X6-MM THK) | 1 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 3 | |
| 9X2043 | 20 SCREW-TRUSS HEAD (M6X1X14-MM) | 10 |
