420-7700 COUPLER GP-QUICK -BLOCK HANDLERType 1

Group No: 420-7700

Part Number	Part Name	Qty
6V9872	1 CONNECTOR	2
1598035	2 FILM-WARNING (CRUSH HAZARD, STAY BACK)	2
1598036	3 FILM-WARNING (READ OMM)	2
1925881	4 PIN	8
4207678	5 PLATE AS (RH)	1
4207685	6 PLATE AS (RH)	1
4207701	8 FRAME AS-COUPLER	1
2C9259	8A PLATE-IDENTIFICATION (CAT)	2
4E5591	8B RETAINER	3
2791020	8C PLATE (PROTECTOR)	1
4207706	9 PLATE AS (LH)	1
4413280	10 PLATE AS (LH)	1
3B4631	12 PIN-COTTER	8
3H0122	13 FITTING-GREASE	8
5P7464	14 CLIP (SLOT)	2
5P7465	15 CLIP (TAB)	2
6V7359	16 GROMMET (25-MM ID, 37-MM OD)	2
8T4121	17 WASHER-HARD (11X21X2.5-MM THK)	34
8T4195	18 BOLT (M10X1.5X30-MM)	34
3E7403	19 ADAPTER	2
1714740	20 COVER	2
3612507	21 CYLINDER GP-COUPLER	4
4207675	22 WEDGE AS	2
4207683	23 HOSE AS	4
4207684	24 HOSE AS	2
4207687	25 WEDGE AS (RH)	1
4207698	26 WEDGE AS (LH)	1
4207707	27 HOSE AS	2
1P3704	28 SEAL-RECTANGULAR	2
3J7354	29 SEAL-O-RING	14
3K0360	30 SEAL-O-RING	2
4J5477	31 SEAL-O-RING	12
6V8397	32 SEAL-O-RING	2
6V8398	33 SEAL-O-RING	4
6V8639	34 CONNECTOR	2
6V8647	35 CONNECTOR	12
6V9830	36 CAP (ORFS)	2
