System And Components
471-3520 COUPLER GP-QUICK -BLOCK HANDLINGFOR USE WITH 447-3050
Group No: 471-3520
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4713527 | 1 PLATE | 1 | |
| 5W2817 | 2 FITTING-GREASE | 6 | |
| 1598035 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 3 | |
| 1598036 | 5 FILM-WARNING (READ OMM) | 2 | |
| 1654934 | 6 PLUG AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9508 | PLUG (11/16-16-THD) | 1 | |
| 1925881 | 7 PIN | 6 | |
| 4522509 | 8 CYLINDER GP-COUPLER (QUICK) | 3 | |
| 4713521 | 9 FRAME AS-COUPLER | 1 | |
| 2C9259 | 9A PLATE-IDENTIFICATION (CAT) | 2 | |
| 9R2640 | 9B BOSS (M12X1.75X25-MM) | 1 | |
| 1477633 | 9C BOSS-TAPPED (M20X2.5X38-MM) | 2 | |
| 2791020 | 9D PLATE (PROTECTOR) | 1 | |
| 4713524 | 10 WEDGE AS | 3 | |
| 4713529 | 11 PLATE AS (LH) | 1 | |
| 4713534 | 12 PLATE AS (RH) | 3 | |
| 4728057 | 13 HOSE AS | 2 | |
| 4728058 | 14 HOSE AS | 2 | |
| 4728059 | 15 HOSE AS | 2 | |
| 1488316 | 16 CONNECTOR AS | 8 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2P1279 | 17 LOCKNUT (9/16-18-THD) | 2 | |
| 3B4631 | 19 PIN-COTTER | 6 | |
| 4J5477 | 20 SEAL-O-RING | 6 | |
| 5759050 | 21 HOSE AS | 2 | |
| 7G2950 | 22 CLIP (SLOT) | 1 | |
| 7G2951 | 23 CLIP (TAB) | 1 | |
| 8C6444 | 24 TEE-BULKHEAD | 2 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4179 | 26 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 14 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
