System And Components
472-8066 COUPLER GP-QUICK -BLOCK HANDLINGFOR USE WITH THIRD VALVE OPTION
Group No: 472-8066
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4179 | 1 BOLT (M12X1.75X20-MM) | 2 | |
| 5W2817 | 2 FITTING-GREASE | 6 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1598035 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 3 | |
| 1598036 | 5 FILM-WARNING (READ OMM) | 2 | |
| 1714740 | 6 COVER | 2 | |
| 1925881 | 7 PIN | 6 | |
| 4522509 | 8 CYLINDER GP-COUPLER (QUICK) | 3 | |
| 4539857 | 9 HOSE AS | 2 | |
| 4713524 | 10 WEDGE AS | 3 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8C6444 | 12 TEE-BULKHEAD | 4 | |
| 4728058 | 13 HOSE AS | 4 | |
| 4728059 | 14 HOSE AS | 4 | |
| 4728067 | 15 FRAME AS-COUPLER | 1 | |
| 2C9259 | PLATE-IDENTIFICATION (CAT) | 2 | |
| 9R2640 | BOSS (M12X1.75X25-MM) | 2 | |
| 1477633 | BOSS-TAPPED (M20X2.5X38-MM) | 2 | |
| 2791020 | PLATE (PROTECTOR) | 1 | |
| 1488316 | 16 CONNECTOR AS | 8 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1689352 | 17 CONNECTOR | 2 | |
| 1P3704 | 18 SEAL-RECTANGULAR | 2 | |
| 2P1279 | 19 LOCKNUT (9/16-18-THD) | 4 | |
| 8T4195 | 20 BOLT (M10X1.5X30-MM) | 14 | |
| 3537954 | 21 GROMMET | 2 | |
| 3B4631 | 22 PIN-COTTER | 6 | |
| 3K0360 | 23 SEAL-O-RING | 2 | |
| 4J5477 | 24 SEAL-O-RING | 12 | |
| 6V8397 | 25 SEAL-O-RING | 4 | |
| 7S3916 | 26 CLIP (TAB) | 2 | |
| 7S3919 | 27 CLIP (SLOT) | 2 |
