System And Components
310-9392 COUPLER GP-QUICK -FUSIONType 4
Group No: 310-9392
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1925881 | 3 PIN | 4 | |
| 2955619 | 4 FILM-WARNING (HAND CRUSH HAZARD, READ OMM) | 1 | |
| 3612507 | 5 CYLINDER GP-COUPLER | 2 | |
| 3445149 | 6 HOSE AS | 2 | |
| 3131418 | 7 WEDGE AS | 2 | |
| 3239427 | 8 FRAME AS-COUPLER | 1 | |
| 2C9259 | PLATE-IDENTIFICATION (CAT) | 2 | |
| 9R2640 | BOSS (M12X1.75X25-MM) | 2 | |
| 1477633 | BOSS-TAPPED (M20X2.5X38-MM) | 3 | |
| 2791020 | PLATE (PROTECTOR) | 1 | |
| 3239430 | 9 HOSE AS | 2 | |
| 1488316 | 10 CONNECTOR AS | 6 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 3B4631 | 11 PIN-COTTER | 4 | |
| 7G2950 | 13 CLIP (SLOT) | 3 | |
| 7G2951 | 14 CLIP (TAB) | 3 | |
| 8T4179 | 15 BOLT (M12X1.75X20-MM) | 3 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 3 |
