System And Components
283-9242 IDLER GP -RHS/N BBX2619-UP
Group No: 283-9242
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2858 | 1 SEAL GP-DUO-CONE | 2 | |
| 1M3097 | 1A RING-SEALING | 2 | |
| 2P0347 | 2 PLUG | 1 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3P8272 | 4 BUSHING AS-IDLER | 2 | |
| 8P6652 | 4A BEARING AS | 1 | |
| 9B2289 | 4B PIN | 2 | |
| 5G9660 | 5 GUARD AS | 1 | |
| 3W8409 | 5A BEARING | 2 | |
| 5G9662 | 6 GUARD AS | 1 | |
| 3W8409 | 6A BEARING | 2 | |
| 5M5000 | 7 LOCK-PIN | 2 | |
| 7P7428 | 8 PIN | 2 | |
| 8G0935 | 9 CAP | 2 | |
| 8Y1853 | 10 STRIP | 2 | |
| 8Y1968 | 11 YOKE AS | 1 | |
| 7P7235 | 11A BUSHING | 2 | |
| 1660613 | 12 SHAFT-TRACK IDLER | 1 | |
| 1662121 | 13 LINK AS | 1 | |
| 7P7864 | SHAFT | 1 | |
| 1662123 | 14 LINK AS | 1 | |
| 7P7864 | SHAFT | 1 | |
| 2284230 | 15 IDLER | 1 | |
| 2592481 | 16 PLATE | 2 | |
| 1H6227 | 17 SEAL-O-RING | 2 | |
| 1S8947 | 18 SEAL-O-RING | 1 | |
| 4J8982 | 19 SEAL-LIP TYPE | 4 | |
| 6J2515 | 20 BOLT-12 POINT HEAD (1/2-13X2.25-IN) | 6 | |
| 7F8268 | 21 SEAL-O-RING | 2 | |
| 7K9203 | 22 SEAL-LIP TYPE | 4 | |
| 7X0311 | 23 BOLT (7/16-14X2.25-IN) | 2 | |
| 7X0563 | 24 WASHER-HARD (12X35X8-MM THK) | 2 | |
| 8G0932 | 25 SPRING-DISC | 4 | |
| 8T4139 | 26 BOLT (M12X1.75X30-MM) | 14 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4244 | 28 NUT (M12X1.75-THD) | 2 | |
| 8T4648 | 29 BOLT (M12X1.75X70-MM) | 2 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 9B7237 | 31 BOLT (3/8-16X1.25-IN) | 12 |
