System And Components
508-7827 LATCH GPS/N LBL1-UP
Group No: 508-7827
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 24 | |
| 8Y6385 | 2 SHIELD-STRIKER | 2 | |
| 9R4872 | 3 CLIP | 2 | |
| 1240597 | 4 KNOB | 2 | |
| 2617382 | 5 LEVER AS | 1 | |
| 2680960 | 6 NUT (M12X1.75-THD) | 2 | |
| 2831409 | 7 PIVOT | 2 | |
| 2835546 | 8 LEVER AS | 1 | |
| 2891081 | 9 CABLE AS | 2 | |
| 2891082 | 10 TURNBUCKLE | 2 | |
| 2891132 | 11 SPRING | 2 | |
| 2943144 | 12 LATCH AS | 2 | |
| 2943159 | 13 BOOT | 2 | |
| 2955742 | 14 STRIKER AS | 2 | |
| 1794324 | 15 LOCKNUT (M5X0.8-THD) | 2 | |
| 3B4504 | 16 LOCKWASHER | 8 | |
| 3E8020 | 17 SCREW-TRUSS HEAD (M6X1X25-MM) | 8 | |
| 4B4274 | 18 WASHER (5.5X13X1.2-MM THK) | 10 | |
| 5C2874 | 19 NUT (M5X0.8-THD) | 8 | |
| 5C2890 | 20 NUT (M6X1-THD) | 8 | |
| 5P4115 | 21 WASHER-HARD (7.2X19X2-MM THK) | 16 | |
| 7I2273 | 22 BOLT (M5X0.8X16-MM) | 2 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 2 |
