Assembly
100%

310-9390 COUPLER GP-QUICKS/N LSJ2703-UP

Group No: 310-9390
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)2
16549342 PLUG AS2
6V8397SEAL-O-RING1
6V9508PLUG (11/16-16-THD)1
29556193 FILM-WARNING (HAND CRUSH HAZARD, READ OMM)1
8T41794 BOLT (M12X1.75X20-MM)3
45225095 CYLINDER GP-COUPLER2
31202176 WEDGE AS2
13540617 HOSE AS2
57729338 FRAME AS-COUPLER1
9R2640BOSS (M12X1.75X25-MM)2
4I7077BOSS3
3120224BOSS2
2C92598A PLATE-IDENTIFICATION (CAT)2
27910208B PLATE (PROTECTOR)1
29241368C PLATE2
32328408D PLATE1
32358719 HOSE AS2
8T422310 WASHER-HARD (13.5X25.5X3-MM THK)3
3B463111 PIN-COTTER4
7G295112 CLIP (TAB)3
7G295013 CLIP (SLOT)3
148831614 CONNECTOR AS6
3J7354SEAL-O-RING1
4J5477SEAL-O-RING1
6V8647CONNECTOR1
192588115 PIN4
