236-8978 LADDER GPS/N WLA1-UP

Group No: 236-8978
Part NumberPart NameQty
7W81061 SPACER (11.13X19.05X15-MM THK)32
23415302 STEP AS6
23415313 STEP1
23435454 PLATE12
23451076 SUPPORT-STEP (RUBBER)8
24363907 HANDRAIL AS (LH)1
24363918 HANDRAIL AS (RH)1
24364099 HANDRAIL AS (LH)1
243641010 HANDRAIL AS (RH)1
244354111 LADDER AS (LH)1
245908713 LADDER AS (RH)1
368509114 WASHER-HARD (13.5X30X4-MM THK)6
368509015 WASHER-HARD (11X25X3-MM THK)4
344119916 WASHER-HARD (11X21X2.5-MM THK)48
368507817 BOLT (M12X1.75X30-MM)17
368507918 BOLT (M10X1.5X40-MM)32
368508019 BOLT (M10X1.5X30-MM)20
279663220 WASHER (13.5X25.5X3-MM THK)12
339575721 PLATE2
339575822 PLATE2
259262723 BOLT (M12X1.75X40-MM)1
