System And Components
9U-1434 CONTROL GP-PILOT OPERATED HYD -3-FUNCTIONS/N 9JK1-99999
Group No: 9U-1434
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8625 | 1 ELBOW | 1 | |
| 3K0360 | 2 SEAL-O-RING | 1 | |
| 6V9837 | 3 TEE-SWIVEL | 1 | |
| 9X2040 | 4 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 4 | |
| 9X2042 | 5 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 6V8636 | 6 CONNECTOR | 7 | |
| 3J1907 | 7 SEAL-O-RING | 12 | |
| 6V8397 | 8 SEAL-O-RING | 2 | |
| 1021810 | 9 SHEET | 1 | |
| 1021811 | 10 GASKET | 1 | |
| 6E5020 | 11 VALVE GP-PILOT (3-FUNCTION) | 1 | |
| 3S2093 | 12 STRAP-CABLE | 6 | |
| 1130958 | 13 KNOB | 2 | |
| 8T4244 | 14 NUT (M12X1.75-THD) | 3 | |
| 1130957 | 15 ROD | 2 | |
| 6V8724 | 16 ELBOW | 3 | |
| 1304531 | 17 VALVE GP-MANUAL | 1 | |
| 6E4546 | KIT-SEAL | 1 | |
| 8C0564 | 18 CONNECTOR | 1 | |
| 9C1250 | 19 HOSE AS | 1 | |
| 1130905 | 20 LEVER | 1 | |
| 4B4276 | 21 WASHER (7X16X1.6-MM THK) | 1 | |
| 1043601 | 22 SCREW-MACHINE (M5X0.8X25-MM) | 1 | |
| 8T0286 | 23 BOLT (M5X0.8X8-MM) | 4 | |
| 4E7822 | 24 CONTROL GP-HANDLE | 1 | |
| 1064540 | 25 ROD | 1 | |
| 8T6885 | 26 TUBE-HEAT SHRINK (19.05-MM DIA)(7 CM) | ||
| 8L8413 | 27 STRAP-CABLE (WHITE) | 1 | |
| 8T4244 | 28 NUT (M12X1.75-THD) | 1 | |
| 8R7729 | 29 HANDLE | 1 | |
| 6V9505 | 30 SCREW-MACHINE (M3X0.5X25-MM) | 2 | |
| 8R7730 | 31 COVER-HANDLE | 1 | |
| 4E3949 | 32 BOOT | 1 | |
| 9X4959 | 33 SWITCH AS-PUSH BUTTON | 1 | |
| 4E7462 | 34 HARNESS AS-SWITCH (DOWNSHIFT) | 1 | |
| 6V8183 | 35 NUT-FULL (3/8-24-THD) | 2 | |
| 8T6876 | 36 ELBOW | 1 | |
| 6V8398 | 37 SEAL-O-RING | 3 | |
| 4E9271 | 38 HOSE AS | 1 | |
| 8T4896 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
