System And Components
4E-8692 INSTALLATION GP-GOV CONTROLS/N 9JK1-358
Group No: 4E-8692
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S7446 | 1 SCREW-MACHINE (8-32X0.437-IN) | 6 | |
| 1H4393 | LOCKWASHER | 6 | |
| 8T4896 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8M2770 | 3 CLIP (LOOP) | 3 | |
| 4M6425 | 4 BOLT (5/16-18X1-IN) | 2 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X0391 | 5 CABLE AS | 1 | |
| 1V6341 | 6 SEAL | 2 | |
| 6V8801 | 7 NUT (3/8-16-THD) | 3 | |
| 6L7751 | 8 ROD END | 1 | |
| 8R3675 | 9 GUIDE | 2 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 1 | |
| 8V1623 | 11 SEAL | 1 | |
| 8T4205 | 12 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 4M5281 | 13 BOLT (1/4-20X0.75-IN) | 1 | |
| 8V1622 | 14 HOUSING | 1 | |
| 8V1624 | 15 LEVER | 1 | |
| 2S1865 | 16 BRACKET | 1 | |
| 8R3674 | 17 GUIDE | 1 | |
| 8V1625 | 18 GASKET | 1 | |
| 8V1626 | 19 COVER | 1 | |
| 6V8187 | 20 NUT (1/4-28-THD) | 3 | |
| 5P6438 | 21 END-YOKE ROD | 1 | |
| 2V7859 | 22 BEARING | 2 | |
| 8J5839 | 23 SPRING | 1 | |
| 8T8932 | 24 PIN AS-SPRING | 1 |
