System And Components
8E-9108 PLANETARY GP-TRANSMISSIONS/N 5YX920-99999
Group No: 8E-9108
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9P7757 | 1 GEAR-SUN (42-TEETH) | 1 | |
| 0616711 | 2 RING-RETAINING | 1 | |
| 5P5296 | 3 RING-RETAINING | 2 | |
| 9P8626 | 4 GEAR-SUN (42-TEETH) | 1 | |
| 7T8816 | 5 BALL BEARING | 2 | |
| 6V0473 | 6 RING-RETAINING | 2 | |
| 3K2511 | 7 DOWEL-REACTION | 5 | |
| 9M4355 | 8 DAMPER-BOLT | 10 | |
| 8P2049 | 9 HOUSING AS-CLUTCH | 1 | |
| 1A2223 | DOWEL | 4 | |
| 8P2019 | 10 RING-SEAL | 1 | |
| 8P2022 | 11 RING-SEAL | 2 | |
| 4M9592 | 12 SPRING | 20 | |
| 8P1892 | 13 PISTON-CLUTCH | 2 | |
| 9W8433 | 14 SHAFT AS-OUTPUT | 1 | |
| 9G6744 | 15 BUSHING | 1 | |
| 9G6743 | 16 BUSHING | 1 | |
| 5M3038 | 17 SEAL-O-RING | 1 | |
| 8E8299 | 18 DISC-THRUST | 12 | |
| 8P1916 | 19 GEAR-PLANETARY (20-TEETH) | 3 | |
| 5P3930 | 20 BEARING AS-ROLLER | 3 | |
| 3S2708 | 21 PIN-SPRING | 6 | |
| 9G0289 | 22 SHAFT-PLANETARY | 3 | |
| 8P2047 | 23 RING-LOCK | 1 | |
| 7G7218 | 24 CARRIER-PLANETARY | 1 | |
| 7T9370 | 25 GEAR-SUN (51-TEETH) | 1 | |
| 8P2051 | 26 PLATE-CLUTCH | 3 | |
| 6Y5911 | 27 DISC-FRICTION | 5 | |
| 9G0291 | 28 GEAR-RING (90-TEETH) | 1 | |
| 9P8283 | 29 PLATE-CLUTCH | 1 | |
| 9G0290 | 30 HUB-CLUTCH | 1 | |
| 6Y5912 | 31 DISC-FRICTION | 3 | |
| 8P1964 | 32 PLATE-CLUTCH | 2 | |
| 6V2478 | 33 RING-RETAINING | 1 | |
| 9G8020 | 34 PLATE-RETAINER | 1 | |
| 7G2343 | 35 SPRING-DISC | 3 | |
| 7G7724 | 36 PISTON-CLUTCH | 1 | |
| 8P2023 | 37 RING-SEAL | 1 | |
| 8D9739 | 38 SEAL-RING | 1 | |
| 9G0293 | 39 HOUSING AS-CLUTCH | 1 | |
| 4S8537 | 40 DOWEL | 1 | |
| 6P7704 | 41 CARRIER-RING | 1 | |
| 6B6863 | 42 PIN-SPRING | 1 | |
| 7G3975 | 43 RING-RETAINING | 1 | |
| 5P8194 | 44 RING-RETAINING | 1 | |
| 7G2830 | 45 RING-SEAL | 2 | |
| 5P9806 | 46 SEAL-O-RING | 1 | |
| 7G5618 | 47 MANIFOLD AS | 1 | |
| 4L9564 | 48 SEAL-O-RING | 2 | |
| 3S9896 | 49 SEAL-O-RING | 1 | |
| 5P5045 | 50 BALL BEARING | 1 | |
| 1L7388 | 51 RING-RETAINING | 1 | |
| 5P5297 | 52 RING-RETAINING (EXTERNAL) | 1 | |
| 9P9031 | 53 GEAR-SUN (47-TEETH) | 1 | |
| 9P3731 | 54 CARRIER-PLANETARY | 1 | |
| 8P1918 | 55 GEAR-PLANETARY (20-TEETH) | 3 | |
| 2S0669 | 56 BEARING | 6 | |
| 8P2042 | 57 SHAFT-PLANETARY | 3 | |
| 7J6580 | 58 RING-RETAINING | 1 | |
| 9P8516 | 59 GEAR-RING (85-TEETH) | 1 | |
| 9G0280 | 60 PISTON-CLUTCH | 1 | |
| 9G0281 | 61 RING-SEAL | 1 | |
| 9M4335 | 62 DOWEL-REACTION | 5 | |
| 3T4384 | 63 HOUSING AS-CLUTCH | 1 | |
| 1A2223 | DOWEL | 2 | |
| 5P8245 | 64 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 6J6721 | 65 BOLT (1/2-13X19.25-IN) | 10 | |
| 7G5670 | 66 SEAL-RING | 1 | |
| 1A1952 | 67 BOLT (1/2-20X3.75-IN) | 1 | |
| 8E3472 | 68 RETAINER | 1 | |
| 8E7448 | 69 GEAR-TRANSFER (61-TEETH) | 1 | |
| 6V4351 | 70 PLATE-INNER RACE | 1 | |
| 0673161 | 71 RING-RETAINING | 1 | |
| 5K8591 | 72 BEARING-OUTER | 1 | |
| 6V4350 | 73 RACE-ROLLER BEARING | 1 | |
| 6Y4767 | 74 HOUSING AS | 1 | |
| 3P7009 | 75 PLUG-CUP | 1 | |
| 6H7201 | 76 RING-METAL SEAL | 2 | |
| 3S2708 | 77 PIN-SPRING | 7 | |
| 9W3605 | 78 CARRIER-RING | 1 | |
| 9G0281 | 79 RING-SEAL | 1 | |
| 8P2022 | 80 RING-SEAL | 3 | |
| 9G0280 | 81 PISTON-CLUTCH | 1 | |
| 9P7390 | 82 DISC AS-FRICTION | 8 | |
| 8P2051 | 83 PLATE-CLUTCH | 8 | |
| 6Y1602 | 84 COUPLING | 1 | |
| 3K2511 | 85 DOWEL-REACTION | 5 | |
| 9W9069 | 86 SHAFT-INPUT | 1 | |
| 8M5010 | 87 SEAL-O-RING | 1 | |
| 0688093 | 88 RING-RETAINING | 1 | |
| 8H5352 | 89 BALL BEARING | 1 | |
| 8P2052 | 90 SEAL-RING | 1 | |
| 6Y4819 | 91 CARRIER-PLANETARY | 1 | |
| 8E8305 | 92 DISC-THRUST | 6 | |
| 8P1919 | 93 GEAR-PLANETARY (27-TEETH) | 3 | |
| 5D2989 | 94 BEARING | 3 | |
| 9P8623 | 95 SHAFT-PLANETARY | 3 | |
| 8P1948 | 96 GEAR-RING (88-TEETH) | 1 | |
| 6Y2054 | 97 PLATE AS | 1 | |
| 5H6202 | PIN | 2 | |
| 9W8437 | 98 GEAR AS-SUN (32-TEETH) | 1 | |
| 5M3038 | 99 SEAL-O-RING | 1 | |
| 6V0473 | 100 RING-RETAINING | 1 | |
| 7T8816 | 101 BALL BEARING | 1 | |
| 8E8304 | 102 DISC-THRUST | 12 | |
| 7G2516 | 103 GEAR-PLANETARY (24-TEETH) | 6 | |
| 5M6126 | 104 BEARING AS-ROLLER | 6 | |
| 9P8624 | 105 SHAFT-PLANETARY | 3 | |
| 8P2047 | 106 RING-LOCK | 2 | |
| 9P3713 | 107 CARRIER-PLANETARY | 1 | |
| 8P2053 | 108 SEAL-RING | 1 | |
| 7G6355 | 109 GEAR-RING (90-TEETH) | 1 | |
| 7H7658 | 110 SPRING | 10 | |
| 9G0285 | 111 PISTON-CLUTCH | 1 | |
| 9G0286 | 112 RING-SEAL | 1 | |
| 9G0284 | 113 HOUSING-CLUTCH | 1 | |
| 1A5183 | 114 BOLT (3/8-16X4.75-IN) | 2 | |
| 9P8614 | 115 GEAR-RING (90-TEETH) | 1 | |
| 6Y5911 | 116 DISC-FRICTION | 3 | |
| 8P9507 | 117 PISTON-CLUTCH | 1 | |
| 4M9592 | 118 SPRING | 10 | |
| 8P2019 | 119 RING-SEAL | 1 |
