System And Components
117-8067 LINES GP-HYD FAN DR & OIL CLRS/N 9JK492-99999
Group No: 117-8067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4223 | 1 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1182460 | 2 VALVE-THERMAL COMPENSATOR | 1 | |
| 3D2824 | 3 SEAL-O-RING | 2 | |
| 1010119 | 4 ADAPTER-PUMP | 1 | |
| 7X0346 | 5 BOLT (5/8-11X2-IN) | 2 | |
| 8T4122 | 6 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8T0788 | 7 ELBOW | 1 | |
| 1182458 | 8 PUMP GP-PISTON (HYDRAULIC FAN) | 1 | |
| 1H6227 | 9 SEAL-O-RING | 1 | |
| 5P2566 | 10 BOLT (1/2-13X1.5-IN) | 2 | |
| 0348348 | 11 HOSE AS | 1 | |
| 6V8721 | 12 ELBOW | 1 | |
| 2H5547 | 13 BUSHING-REDUCER | 1 | |
| 1191341 | 14 ELBOW | 1 | |
| 1193979 | 15 TUBE AS | 1 | |
| 1193980 | 16 TUBE AS | 1 | |
| 1200684 | 17 MANIFOLD | 1 | |
| 6V8635 | 18 CONNECTOR | 2 | |
| 7M8485 | 19 SEAL-O-RING | 4 | |
| 5K9090 | 20 SEAL-O-RING | 13 | |
| 8T1905 | 21 ELBOW | 1 | |
| 3J1907 | 22 SEAL-O-RING | 6 | |
| 6V8636 | 23 CONNECTOR | 1 | |
| 6V8724 | 24 ELBOW | 1 | |
| 6V8397 | 25 SEAL-O-RING | 12 | |
| 6V8998 | 26 UNION | 2 | |
| 6V9172 | 27 NUT (1-7/16-12-THD) | 2 | |
| 6V9840 | 28 TEE-SWIVEL | 1 | |
| 1250048 | 29 HOSE AS | 1 | |
| 6V8792 | 30 TEE-FACE SEAL | 1 | |
| 6V9008 | 31 ELBOW | 1 | |
| 1196404 | 32 HOSE AS | 1 | |
| 1191113 | 33 HOSE AS | 2 | |
| 6V8716 | 34 CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | 35 SEAL-O-RING | 4 | |
| 1196403 | 36 HOSE AS | 1 | |
| 6V8936 | 37 REDUCER | 1 | |
| 2M9780 | 38 SEAL-O-RING | 1 | |
| 7Y4190 | 39 HOSE AS | 1 | |
| 8T8987 | 40 ELBOW | 1 | |
| 2S4078 | 41 SEAL-O-RING | 1 | |
| 1196406 | 42 HOSE AS | 1 | |
| 6V9007 | 43 ELBOW | 1 | |
| 6V9839 | 44 TEE-SWIVEL | 1 | |
| 6V8556 | 45 NUT (1-3/16-12-THD) | 1 | |
| 1200685 | 46 ADAPTER | 1 | |
| 9X2614 | 47 CONNECTOR | 1 | |
| 6V9850 | 48 ELBOW (90 DEGREE) | 1 | |
| 6V9161 | 49 TEE | 1 | |
| 3J7354 | 50 SEAL-O-RING | 1 | |
| 6V8723 | 51 ELBOW | 1 | |
| 3K0360 | 52 SEAL-O-RING | 1 | |
| 1196407 | 53 CONNECTOR | 2 | |
| 8T7876 | 54 SEAL-O-RING | 2 | |
| 1196409 | 55 BRACKET | 1 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 57 NUT (M10X1.5-THD) | 2 | |
| 8T3647 | 58 BOLT (M8X1.25X80-MM) | 3 | |
| 5C7261 | 59 NUT (M8X1.25-THD) | 3 | |
| 8T4224 | 60 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 1225775 | 61 HOSE AS | 1 | |
| 8T6907 | 62 VALVE-BALL | 1 | |
| 8T6663 | 63 ADAPTER-PORT | 1 | |
| 8R0616 | 64 HOSE AS | 1 | |
| 9C2080 | 65 HOSE AS | 1 | |
| 0875762 | 66 HOSE AS | 2 | |
| 2N1287 | 67 ELBOW-FLARED | 2 | |
| 6V8398 | 68 SEAL-O-RING | 3 | |
| 1010473 | 69 GASKET | 1 | |
| 7X3360 | 70 BOLT | 3 | |
| 6K0806 | 71 STRAP-CABLE | 2 | |
| 6V8944 | 72 REDUCER | 2 | |
| 6V8557 | 73 NUT-FACE SEAL (1-7/16-12-THD) | 2 |
