System And Components
191-1265 CONTROL GP-SERVICE BRAKES/N MHG1015-3999
Group No: 191-1265
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4607 | 1 PIN-COTTER | 2 | |
| 5P6724 | 2 BEARING-ROLLER | 1 | |
| 6V0852 | 3 CAP-DUST | 3 | |
| 7I4078 | 4 LEVER AS | 1 | |
| 8R9137 | 5 ANGLE | 1 | |
| 9V6538 | 6 CLAMP | 1 | |
| 0911745 | 7 WASHER (16.6X24X1.2-MM THK) | 6 | |
| 1061774 | 8 VALVE GP-BRAKE CONTROL (PARKING) | 1 | |
| 3010360 | 9 ACCUMULATOR GP-BRAKE (CHARGED) | 2 | |
| 1158426 | 10 TUBE AS | 2 | |
| 1158433 | 11 TUBE AS | 1 | |
| 1158434 | 12 BRACKET AS | 1 | |
| 1158435 | 13 TUBE AS | 1 | |
| 3010357 | 14 HOSE AS | 1 | |
| 1384409 | 15 SPACER (10.5X22X35-MM THK) | 2 | |
| 1473712 | 16 ROD-CONTROL | 1 | |
| 1503065 | 17 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V0484 | ELBOW | 1 | |
| 1630922 | 18 TUBE AS | 1 | |
| 1690527 | 19 HOSE AS | 1 | |
| 1690528 | 20 HOSE AS | 1 | |
| 1590224 | 21 HOSE AS | 1 | |
| 1690531 | 22 BRACKET AS | 1 | |
| 1715368 | 23 HOSE AS | 1 | |
| 1715367 | 24 HOSE AS | 1 | |
| 1716671 | 25 HOSE AS | 1 | |
| 1716712 | 26 TEE AS | 2 | |
| 1566400 | TEE-SWIVEL-ORFS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1716718 | 27 TEE AS | 2 | |
| 1057704 | TEE | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1725761 | 28 TEE AS | 2 | |
| 1268306 | TEE | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3040731 | 29 VALVE GP-ACCUMULATOR CHARGING (BRAKE) | 1 | |
| 1763890 | 30 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 1850002 | 31 REDUCER AS | 1 | |
| 6V8947 | REDUCER | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1964905 | 32 BRACKET AS | 1 | |
| 1965536 | 33 HOSE AS | 1 | |
| 1965537 | 34 HOSE AS | 1 | |
| 1966090 | 35 TUBE AS | 1 | |
| 2954738 | 36 HOSE AS | 1 | |
| 2100235 | 37 BRACKET | 1 | |
| 2511093 | 38 TUBE AS | 1 | |
| 2609632 | 39 VALVE GP-BRAKE CONTROL (SERVICE) | 1 | |
| 1177798 | BOOT | 1 | |
| 1177799 | KIT-SEAL (BRAKE VALVE) | 1 | |
| 1488307 | 40 ADAPTER AS | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488328 | 41 CONNECTOR AS | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488340 | 42 CONNECTOR AS | 4 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488346 | 43 ELBOW AS | 2 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488353 | 44 ELBOW AS | 1 | |
| 6V9001 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488364 | 45 ELBOW AS | 4 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488365 | 46 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488370 | 47 ELBOW AS | 7 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488371 | 48 ELBOW AS | 1 | |
| 8C8988 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488373 | 49 ELBOW AS | 1 | |
| 8C3364 | ELBOW | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488378 | 50 ELBOW AS | 4 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488435 | 51 TEE AS | 1 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488444 | 52 TEE AS-SWIVEL | 3 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1645567 | 53 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1S0994 | 54 CLIP (LOOP) | 17 | |
| 3B4640 | 55 PIN-COTTER | 1 | |
| 5P9299 | 56 CLIP (LOOP) | 2 | |
| 6D1641 | 57 CLIP (LOOP) | 3 | |
| 6D4247 | 58 CLIP | 1 | |
| 6M5062 | 59 SEAL-O-RING | 1 | |
| 6V8398 | 60 SEAL-O-RING | 4 | |
| 6V8400 | 61 SEAL-O-RING | 1 | |
| 7X2618 | 62 PIN | 2 | |
| 7X7729 | 63 WASHER (11X25X3-MM THK) | 2 | |
| 8S0948 | 64 CLIP | 1 | |
| 8T0741 | 65 SEAL-LIP TYPE | 2 | |
| 8T4121 | 66 WASHER-HARD (11X21X2.5-MM THK) | 46 | |
| 8T4133 | 67 NUT (M10X1.5-THD) | 5 | |
| 8T4136 | 68 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 69 BOLT (M10X1.5X20-MM) | 21 | |
| 8T4189 | 70 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4192 | 71 BOLT (M12X1.75X25-MM) | 6 | |
| 8T4195 | 72 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4223 | 73 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4224 | 74 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6466 | 75 BOLT (M10X1.5X60-MM) | 2 | |
| 9X6578 | 76 NUT-FACE SEAL (1-11/16-12-THD) | 1 | |
| 9X8250 | 77 CLIP (LOOP) | 6 | |
| 9X8257 | 78 WASHER (17.5X30X3.5-MM THK) | 1 | |
| 6D4244 | 79 CLIP (LOOP) | 1 | |
| 1473150 | 80 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1186878 | 81 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1393285 | KIT-BRAKE CHARGE VALVE |
