System And Components
189-7001 LINES GP-AUTOMATIC LUBRICATION -CUSTOMS/N 2KR4553-UP
Group No: 189-7001
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K9243 | 1 ELBOW-FLARED | 2 | |
| 5K9979 | 2 CONNECTOR | 2 | |
| 1601744 | 3 BRACKET | 1 | |
| 1717192 | 4 LINES GP-LUBRICATION (AXLES, STEER CYL'S,LOWER HITCH) | 1 | |
| 1717193 | 5 LINES GP-LUBRICATION (BKT CONT; STEER CYL; UP HITCH) | 1 | |
| 1717194 | 6 LINES GP-LUBRICATION (TILT CYL; LINKS; BELL CRANK) | 2 | |
| 1718806 | 7 BRACKET AS | 1 | |
| 1718823 | 8 TANK GP-GREASE | 1 | |
| 1718861 | 9 BRACKET | 2 | |
| 1748214 | 10 GUARD AS | 2 | |
| 1861624 | 11 GUARD | 2 | |
| 1897003 | 12 LINES GP-LUBRICATION (B-PINS, LEVERS, FRAMES) | 1 | |
| 1897042 | 13 TUBE AS | 1 | |
| 1897043 | 14 TUBE AS | 1 | |
| 1308433 | 15 GROMMET | 4 | |
| 4D7794 | 16 CLIP | 29 | |
| 4K3026 | 17 EXTENSION (FITTING) | 2 | |
| 4K8864 | 18 CLIP | 12 | |
| 5C2890 | 19 NUT (M6X1-THD) | 6 | |
| 6V4356 | 20 CLIP (SLOT) | 4 | |
| 6V4357 | 21 CLIP (TAB) | 4 | |
| 7X2534 | 22 BOLT (M6X1X50-MM) | 10 | |
| 7X2552 | 23 BOLT (M16X2X30-MM) | 3 | |
| 8M2772 | 24 CLIP | 2 | |
| 8M2773 | 25 CLIP | 6 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 63 | |
| 8T4133 | 27 NUT (M10X1.5-THD) | 35 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4137 | 29 BOLT (M10X1.5X20-MM) | 14 | |
| 8T4186 | 30 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 31 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 33 BOLT (M12X1.75X35-MM) | 8 | |
| 9M8406 | 34 CLIP | 1 | |
| 9X8256 | 35 WASHER (6.6X12X2-MM THK) | 16 | |
| 9X8257 | 36 WASHER (17.5X30X3.5-MM THK) | 3 |
