Assembly
100%

1V-5971 CONTROL GP-BUCKETS/N 49Z291-1113

Group No: 1V-5971
Part NumberPart NameQty
7V04981 ARM & BEARING AS-LIFT1
1V56361A BUSHING2
12125301B PLATE1
4E3486CROSSMEMBER1
4V0673PLATE1
5V9074ARM AS-LIFT1
4V06731C PLATE2
4V33831D PLATE2
9U20211E CROSSMEMBER1
5V9075PLATE AS2
5V90771F BRACKET1
5V90781G BRACKET1
5V90791H BOSS (LH)1
5V90801J BOSS (RH)1
10074331K BOSS-REAR2
6W70282 LEVER & BUSHING AS2
1V70382A BUSHING1
8R39313 COLLET4
03305124 BOLT (1-1/4-7-THD)2
4K06845 WASHER-HARD (34X55X6-MM THK)8
3K97706 NUT-FULL (1-1/4-7-THD)6
1V80317 PIN2
5P23228 SEAL-LIP TYPE8
6J15369 BOLT (7/8-9X6.5-IN)8
4M695310 WASHER-HARD (24X38X3.5-MM THK)8
7V232111 BAR2
8B824512 BUSHING-TERMINAL4
4V730313 BOLT4
5V901414 LINK & BEARING AS2
1K261614A SPACER (21.6X27.2X33.3-MM THK)2
1V563514B BUSHING1
4V730314C BOLT2
5V8971LINK AS1
5V891114D PLATE1
7X042614E BOLT3
7X045014F NUT-FULL (1-1/8-7-THD)3
7X053114G WASHER-HARD (31X52.5X6-MM THK)6
5P766915 BOLT (1-1/4-7X16-IN)2
8R393216 COLLET4
1V803317 PIN2
7K922018 SEAL-LIP TYPE4
9C959619 COLLET AS6
2K807819A PIN-SPRING1
7I418320 PIN AS-CARTRIDGE2
6V276620A PLUG-PIPE2
101786920B BUSHING1
5P779121 BOLT (1-1/4-7X19-IN)2
7I418422 PIN AS-CARTRIDGE2
6V276622A PLUG-PIPE2
101786822B BUSHING1
4V100623 ROD AS2
3K977023A NUT-FULL (1-1/4-7-THD)1
8R393024 COLLET4
4V039925 ROD AS2
3K977025A NUT-FULL (1-1/4-7-THD)1
1V803026 PIN2
7X040827 BOLT (1-8X3.5-IN)6
4V328028 WASHER6
8R452029 COLLET AS2
031025529A PIN-SPRING1
7V290330 WASHER-HARD12
