System And Components
307-0828 CONTROL GP-BUCKETS/N JLK796-UP
Group No: 307-0828
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1V8030 | 1 PIN | 1 | |
| 1V8033 | 2 PIN | 6 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4V0399 | 4 ROD AS | 1 | |
| 3K9770 | NUT-FULL (1-1/4-7-THD) | 1 | |
| 4V2115 | 5 PIN | 4 | |
| 4V2119 | 6 PIN | 2 | |
| 8R3930 | 7 COLLET | 2 | |
| 8R3932 | 8 COLLET | 12 | |
| 9G7516 | 9 PLUG | 42 | |
| 1635519 | 10 PLUG-RUBBER | 36 | |
| 1635521 | 11 SHIM (3-MM THK) | 12 | |
| 1635522 | 12 SHIM (1.6-MM THK) | 12 | |
| 1635835 | 13 SHIM (1.6-MM THK) | 12 | |
| 1635852 | 14 SHIM (3-MM THK) | 12 | |
| 1635857 | 15 SHIM (1.6-MM THK) | 4 | |
| 1869869 | 16 LINK AS-TILT | 1 | |
| 1V5635 | 16A BUSHING | 2 | |
| 2141492 | 17 LEVER AS | 1 | |
| 1V5636 | 17A BUSHING | 1 | |
| 2144332 | 18 PLUG | 36 | |
| 2330920 | 19 PLATE | 2 | |
| 2330924 | 20 PIN AS | 2 | |
| 2779794 | 21 ARM AS-LIFT | 1 | |
| 1V7001 | 21A BUSHING | 2 | |
| 1V7002 | 21B BUSHING | 2 | |
| 1869776 | 21C BEARING | 2 | |
| 3033986 | 22 LOCK GP-PIN (BUCKET CONTROL) | 2 | |
| 3K9770 | 23 NUT-FULL (1-1/4-7-THD) | 11 | |
| 4K0684 | 24 WASHER-HARD (34X55X6-MM THK) | 24 | |
| 5P1075 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P2322 | 26 SEAL-LIP TYPE | 2 | |
| 5P2672 | 27 SEAL-LIP TYPE | 4 | |
| 5P7669 | 28 BOLT (1-1/4-7X16-IN) | 6 | |
| 5P8488 | 29 SEAL-LIP TYPE | 4 | |
| 6V1749 | 30 BOLT (1-1/4-7X17.5-IN) | 4 | |
| 7H3579 | 31 BOLT (1-1/4-12X12-IN) | 2 | |
| 7K9218 | 32 SEAL-LIP TYPE | 4 | |
| 7K9220 | 33 SEAL-LIP TYPE | 4 | |
| 8R3938 | 34 COLLET | 2 | |
| 8R3939 | 35 COLLET | 2 | |
| 8R3942 | 36 COLLET | 8 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T9384 | 38 BOLT (1/2-13X0.875-IN) | 4 | |
| 9B7237 | 39 BOLT (3/8-16X1.25-IN) | 4 |
