System And Components
346-5767 TORQUE CONVERTER GPS/N Z8Z1-UP
Group No: 346-5767
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1T1209 | 1 CARRIER-RING (SEAL) | 1 | |
| 1T1232 | 2 RING-RETAINING | 2 | |
| 1T1244 | 3 WASHER (SPLIT) | 4 | |
| 1T1248 | 4 SLEEVE-WEAR | 1 | |
| 1T1566 | 5 BEARING-THRUST | 1 | |
| 1T1646 | 6 PLATE | 2 | |
| 1T1821 | 7 CARRIER-RING | 1 | |
| 1T1897 | 8 PLATE-CLUTCH | 1 | |
| 1T1898 | 9 PLATE-BACKING | 1 | |
| 1T1925 | 10 GASKET (FLAT) | 1 | |
| 1T2042 | 11 SLEEVE | 1 | |
| 1T2043 | 12 RACE-THRUST BEARING | 1 | |
| 1T2044 | 13 PIN-THRUST RACE | 4 | |
| 3P1669 | 14 RETAINER (SHAFT) | 1 | |
| 3P9497 | 15 PLUG-ORIFICE (7/16-27-THD) | 1 | |
| 5P4055 | 16 BEARING-THRUST | 1 | |
| 6Y6370 | 17 RING-SEAL | 2 | |
| 6Y7198 | 18 PLATE-CLUTCH | 2 | |
| 6Y8167 | 19 WASHER-THRUST (217X280X4.5-MM THK) | 1 | |
| 8E4295 | 20 PISTON-CLUTCH | 1 | |
| 1102138 | 21 GEAR-DRIVE (69-TEETH) | 1 | |
| 1102144 | 22 HOUSING-CLUTCH | 1 | |
| 4718511 | 23 PLATE-CLUTCH BACKING | 1 | |
| 1108847 | 24 STATOR-CONVERTER | 1 | |
| 1108849 | 25 HUB AS | 1 | |
| 1T1253 | 25A BUSHING | 1 | |
| 4L3395 | DOWEL | 4 | |
| 1108852 | 26 RING-SEAL | 3 | |
| 1108853 | 27 CARRIER-STATOR | 1 | |
| 1111275 | 28 PLATE-CLAMP | 1 | |
| 1303639 | 29 SLEEVE | 1 | |
| 1303640 | 30 RACE-THRUST BEARING | 1 | |
| 1410408 | 31 PILOT-FLYWHEEL | 1 | |
| 1410409 | 32 PLATE-RETAINER | 1 | |
| 1418205 | 33 CARRIER-SUPPORT | 1 | |
| 1418387 | 34 CARRIER-RING | 1 | |
| 1555293 | 35 ADAPTER AS-CLUTCH | 1 | |
| 3B2225 | DOWEL | 2 | |
| 1108839 | 35A BUSHING | 1 | |
| 1555716 | DOWEL | 4 | |
| 1555715 | 36 PLATE-THRUST | 2 | |
| 1882595 | 37 RING-SNAP | 1 | |
| 2239743 | 38 SEAL-LIP TYPE | 1 | |
| 3249127 | 39 DISC-FRICTION | 3 | |
| 3261354 | 40 HOUSING AS | 1 | |
| 1555716 | DOWEL | 2 | |
| 3261356 | 41 PISTON | 1 | |
| 3369318 | 42 DISC-FRICTION | 2 | |
| 3465782 | 43 GEAR-DRIVE (75-TEETH) | 1 | |
| 3474326 | 44 SHAFT-OUTPUT | 1 | |
| 3474327 | 45 RETAINER-BEARING | 1 | |
| 3487786 | 46 IMPELLER | 1 | |
| 3487787 | 47 TURBINE | 1 | |
| 3583824 | 48 YOKE AS | 1 | |
| 1T2031 | GUARD | 1 | |
| 0S0509 | 49 BOLT (3/8-16X0.75-IN) | 12 | |
| 0S1595 | 50 BOLT (1/2-13X1.25-IN) | 12 | |
| 1135945 | 51 RING-SEAL | 1 | |
| 1246348 | 52 RACE-ROLLER | 1 | |
| 1281663 | 53 RING-SEAL | 2 | |
| 1410410 | 54 WASHER-SPRING (76X127X10.5-MM THK) | 1 | |
| 1S6478 | 55 RING-SEAL | 1 | |
| 1T1365 | 56 CARRIER-RING | 1 | |
| 2H2255 | 57 DOWEL | 1 | |
| 3D4603 | 58 PLUG-PIPE | 1 | |
| 3L1824 | 59 BALL BEARING | 1 | |
| 3S0142 | 60 RING-SEAL | 1 | |
| 3S1282 | 61 RING-SEAL | 1 | |
| 4K5175 | 62 BOLT-12 POINT HEAD (1/2-13X1.5-IN) | 20 | |
| 4M5227 | 63 BALL BEARING | 1 | |
| 5H2824 | 64 SEAL-O-RING | 1 | |
| 5P6408 | 65 BEARING-INNER | 1 | |
| 5P8245 | 66 WASHER-HARD (13.5X25.5X3-MM THK) | 42 | |
| 7L3385 | 67 SEAL-O-RING | 1 | |
| 7S6892 | 68 RING-SEAL | 1 | |
| 7X0349 | 69 BOLT (5/8-11X3-IN) | 1 | |
| 8L2786 | 70 SEAL-O-RING | 2 | |
| 8T4896 | 71 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 9B7237 | 72 BOLT (3/8-16X1.25-IN) | 11 | |
| 9S4185 | 73 PLUG (3/4-16-THD) | 2 | |
| 9S8008 | 74 PLUG (1-1/16-12-THD) | 1 | |
| 9S9739 | 75 BOLT (1/2-13X2.7-IN) | 12 | |
| 9X8873 | 76 BOLT (1/2-13X2.25-IN) | 3 | |
| 9X8876 | 77 BOLT (1/2-13X4.75-IN) | 30 | |
| 9X8883 | 78 BOLT (5/8-11X2.75-IN) | 12 |
