System And Components
2Q-8517 CONVERSION GP-BUCKET CONTROLS/N ADZ1-UP
Group No: 2Q-8517
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3V4943 | 1 HOSE AS | 2 | |
| 5B0935 | 2 FITTING-GREASE | 2 | |
| 5K9242 | 3 UNION-FLARED | 1 | |
| 5K9243 | 4 ELBOW-FLARED | 2 | |
| 5K9979 | 5 CONNECTOR | 2 | |
| 5P5461 | 6 NUT (1/8-27-THD) | 6 | |
| 5P5463 | 7 ADAPTER-LUBRICATION | 2 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 9U0900 | 9 PLATE | 1 | |
| 1062105 | 10 ELBOW | 2 | |
| 2070699 | 11 TUBE AS | 1 | |
| 2070701 | 12 TUBE AS | 1 | |
| 2070702 | 13 TUBE AS | 1 | |
| 2213456 | 14 TUBE AS | 1 | |
| 2213457 | 15 TUBE AS | 1 | |
| 3J1907 | 16 SEAL-O-RING | 2 | |
| 4M5317 | 17 BUSHING-REDUCER | 2 | |
| 8M2772 | 18 CLIP (LOOP) | 9 | |
| 8T4133 | 19 NUT (M10X1.5-THD) | 9 | |
| 1102023 | 20 STUD-WELD (M10X1.5X25-MM) | 7 | |
| 8T4219 | 21 STUD-WELD (M10X1.5X17.5-MM) | 2 | |
| 1K6853 | 22 FITTING-PRESSURE RELIEF | 5 | |
| 1488331 | 23 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3Y2888 | CONNECTOR | 1 | |
| 2043582 | 24 PLATE AS | 3 | |
| 1S9292 | DOWEL | 2 | |
| 2043583 | 25 PLATE AS | 3 | |
| 1S9292 | DOWEL | 2 | |
| 2043586 | 26 PLATE | 2 | |
| 2128201 | 27 PLATE | 2 | |
| 2289569 | 28 PIN AS | 1 | |
| 1461799 | 29 WASHER-HARD (39X66X6-MM THK) | 1 | |
| 1488407 | 30 PLUG AS | 9 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 8T1605 | 31 BOLT (M36X4X100-MM) | 1 | |
| 1K6853 | 32 FITTING-PRESSURE RELIEF | 2 | |
| 1488331 | 33 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3Y2888 | CONNECTOR | 1 | |
| 2289569 | 34 PIN AS | 1 | |
| 2368090 | 35 PLATE AS | 1 | |
| 1461799 | 36 WASHER-HARD (39X66X6-MM THK) | 1 | |
| 1488407 | 37 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 8T1605 | 38 BOLT (M36X4X100-MM) | 1 |
