System And Components
345-0290 LINES GP-AUTOMATIC LUBRICATIONS/N ZMX1-UP
Group No: 345-0290
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K9243 | 1 ELBOW-FLARED | 3 | |
| 1277474 | 2 PLATE | 1 | |
| 1277475 | 3 PLATE | 1 | |
| 1545232 | 4 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1129783 | ADAPTER | 1 | |
| 1716727 | 5 ADAPTER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T4128 | ADAPTER | 1 | |
| 2042281 | 6 STRAP-CABLE | 8 | |
| 2048000 | 7 MOUNTING-CABLE TIE | 8 | |
| 2350368 | 8 BRACKET | 1 | |
| 2482169 | 9 SENSOR GP-PRESSURE | 1 | |
| 2609187 | 10 CONNECTOR AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T9358 | CONNECTOR | 1 | |
| 2695353 | 11 VALVE GP-LUBE DISTRIBUTION (5-INJECTOR) | 1 | |
| 2842873 | 12 HOSE AS | 1 | |
| 2842874 | 13 HOSE AS | 1 | |
| 2977948 | 14 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1010052 | TEE-UNION | 1 | |
| 3441950 | 15 CLIP (SLOT) | 3 | |
| 3450314 | 16 TUBE AS | 1 | |
| 3450316 | 17 TUBE AS | 1 | |
| 3450317 | 18 TUBE AS | 1 | |
| 3450318 | 19 TUBE AS | 1 | |
| 3450319 | 20 TUBE AS | 1 | |
| 3450321 | 21 TUBE AS | 1 | |
| 3450322 | 22 TUBE AS | 1 | |
| 3450323 | 23 TUBE AS | 1 | |
| 3450324 | 24 TUBE AS | 1 | |
| 3450326 | 25 TUBE AS | 1 | |
| 3450327 | 26 TUBE AS | 1 | |
| 3450328 | 27 TUBE AS | 1 | |
| 3450329 | 28 TUBE AS | 1 | |
| 3450344 | 29 HOSE AS | 1 | |
| 3478775 | 30 TUBE AS | 1 | |
| 3478776 | 31 HOSE AS | 1 | |
| 3610981 | 32 TUBE AS | 1 | |
| 1108796 | 33 PIPE | 1 | |
| 1488320 | 34 CONNECTOR AS | 5 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1488351 | 35 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488354 | 36 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488384 | 37 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8979 | ELBOW | 1 | |
| 1488444 | 38 TEE AS-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1504052 | 39 UNION AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8993 | UNION | 1 | |
| 1716731 | 40 CONNECTOR AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C6871 | CONNECTOR | 1 | |
| 1J9671 | 41 SEAL-O-RING | 1 | |
| 2977958 | 42 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2053079 | ADAPTER | 1 | |
| 2A2677 | 43 SPACER (10.7X17.14X19.05-MM THK) | 1 | |
| 2P1279 | 44 LOCKNUT (9/16-18-THD) | 2 | |
| 3441951 | 45 CLIP (TAB) | 3 | |
| 3J5390 | 46 PLUG (3/8-18-THD) | 1 | |
| 4J5477 | 47 SEAL-O-RING | 9 | |
| 5K2298 | 48 CLIP | 6 | |
| 6V8398 | 49 SEAL-O-RING | 1 | |
| 6V9168 | 50 NUT (11/16-16-THD) | 1 | |
| 7X7729 | 51 WASHER (11X25X3-MM THK) | 4 | |
| 8M2772 | 52 CLIP (LOOP) | 15 | |
| 8T4121 | 53 WASHER-HARD (11X21X2.5-MM THK) | 27 | |
| 8T4136 | 54 BOLT (M10X1.5X25-MM) | 13 | |
| 8T4137 | 55 BOLT (M10X1.5X20-MM) | 17 | |
| 8T4185 | 57 BOLT (M10X1.5X50-MM) | 3 | |
| 9X2027 | 58 WASHER (11X18X2-MM THK) | 2 | |
| 4200939 | 59 SPACER (11.3X12.7X8.7-MM THK)(RED) | 4 | |
| 4200942 | 60 SPACER (11.3X12.7X12-MM THK)(GREEN) | 1 |
