System And Components
510-6203 FIREWALL GP -SUPPRESSIONS/N 8801-UP
Group No: 510-6203
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X2393 | 1 BUMPER-CONICAL | 1 | |
| 3053155 | 2 PAWL | 1 | |
| 3260610 | 3 LATCH AS | 1 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0966331 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 3323482 | 4 SUPPORT AS | 1 | |
| 3477988 | 5 STRIP | 3 | |
| 3493326 | 6 DOOR GP-ACCESS | 1 | |
| 3703982 | 7 SUPPORT AS | 2 | |
| 2678821 | 8 WASHER (17X36X12-MM THK) | 12 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 7X2554 | 10 BOLT (M16X2X70-MM) | 12 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 19 | |
| 8T4195 | 12 BOLT (M10X1.5X30-MM) | 19 | |
| 7X7898 | 13 TRIM (30-CM) |
