System And Components
352-5285 LINES GP-HYDRAULICS/N Z4Z1-382
Group No: 352-5285
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1521332 | 1 SPACER (10.2X18.5X6.35-MM THK) | 12 | |
| 1527996 | 2 HOSE | 3 | |
| 7Y4562 | 3 HOSE (22-CM) | ||
| 2429557 | 4 MOUNT AS | 10 | |
| 2800026 | 5 MANIFOLD | 1 | |
| 2956102 | 6 TUBE AS | 3 | |
| 2956103 | 7 TUBE AS | 1 | |
| 2956929 | 8 TUBE AS | 3 | |
| 3599712 | 9 TUBE AS | 1 | |
| 3599713 | 10 TUBE AS | 1 | |
| 3599715 | 11 TUBE AS | 1 | |
| 3628072 | 12 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3633216 | 13 VALVE & MTG GP-IMPLEMENT (CHECK) | 1 | |
| 3637256 | 14 HOSE AS | 1 | |
| 3637496 | 15 SUPPORT | 3 | |
| 3696860 | 16 PLUG AS | 1 | |
| 0304606 | SEAL-O-RING | 1 | |
| 3603700 | PLUG | 1 | |
| 3832012 | 17 HOSE AS | 1 | |
| 3832013 | 18 HOSE AS | 1 | |
| 3832015 | 19 HOSE AS | 2 | |
| 3832020 | 20 PLATE AS | 1 | |
| 1598759 | BLOCK | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3851113 | 21 MANIFOLD | 1 | |
| 3851114 | 22 PLATE | 1 | |
| 3851116 | 23 BRACKET AS | 2 | |
| 3851115 | BRACKET | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3871769 | 24 HOSE | 3 | |
| 3884155 | 25 TUBE AS | 1 | |
| 3884157 | 26 TUBE AS | 1 | |
| 3985366 | 27 HOSE AS | 2 | |
| 3985367 | 28 HOSE AS | 1 | |
| 3985368 | 29 HOSE AS | 1 | |
| 0950705 | 30 BOLT-SOCKET HEAD (M16X2X100-MM) | 4 | |
| 1031303 | 31 CLAMP-HALF | 4 | |
| 1488334 | 32 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 1488407 | 33 PLUG AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1600012 | 34 CLIP (SLOT) | 2 | |
| 1600013 | 35 CLIP (TAB) | 2 | |
| 1P3705 | 36 SEAL-RECTANGULAR | 8 | |
| 1P3707 | 37 SEAL-RECTANGULAR | 1 | |
| 1P3709 | 38 SEAL-RECTANGULAR | 2 | |
| 1P4578 | 39 FLANGE-HALF | 2 | |
| 1P4582 | 40 FLANGE-HALF | 16 | |
| 2118073 | 41 CAP-PROTECTION | 16 | |
| 3431820 | 42 CLAMP-BAND | 2 | |
| 3464788 | 43 CLAMP-BAND | 12 | |
| 3464791 | 44 CLAMP-BAND | 4 | |
| 3E9411 | 45 WASHER-HARD (17.5X38X6-MM THK) | 8 | |
| 1757902 | 46 SEAL-O-RING | 2 | |
| 4J0522 | 47 SEAL-O-RING | 1 | |
| 4J0527 | 48 SEAL-O-RING | 8 | |
| 5P8077 | 49 FLANGE-HALF | 10 | |
| 6V1574 | 50 GROMMET | 2 | |
| 6V1870 | 51 CLIP (SLOT) | 2 | |
| 6V1871 | 52 CLIP (TAB) | 2 | |
| 6V1872 | 53 GROMMET | 2 | |
| 7G8839 | 54 SPACER (13.5X57X6-MM THK) | 20 | |
| 7X2553 | 55 BOLT (M16X2X40-MM) | 4 | |
| 7X2554 | 56 BOLT (M16X2X70-MM) | 4 | |
| 7X7729 | 57 WASHER (11X25X3-MM THK) | 2 | |
| 8T0348 | 58 BOLT-SOCKET HEAD (M16X2X50-MM) | 4 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4123 | 60 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4140 | 61 BOLT (M16X2X60-MM) | 22 | |
| 8T4141 | 62 BOLT (M20X2.5X70-MM) | 8 | |
| 8T4183 | 63 BOLT (M12X1.75X40-MM) | 34 | |
| 8T4186 | 64 BOLT (M10X1.5X40-MM) | 6 | |
| 8T4193 | 65 BOLT (M16X2X50-MM) | 22 | |
| 8T4195 | 66 BOLT (M10X1.5X30-MM) | 8 | |
| 1837121 | 67 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4222 | 68 WASHER-PLATED (11X32X2.5-MM THK) | 12 | |
| 8T4223 | 69 WASHER-HARD (13.5X25.5X3-MM THK) | 40 | |
| 8T4987 | 70 CLAMP-HOSE | 12 | |
| 8T6868 | 71 BOLT (M12X1.75X80-MM) | 10 | |
| 8T7338 | 72 BOLT (M16X2X45-MM) | 6 | |
| 9F7283 | 73 SEAL-O-RING | 3 | |
| 9M2092 | 74 SEAL-O-RING | 1 | |
| 9X7440 | 75 SEAL-O-RING | 3 | |
| 9X8257 | 76 WASHER (17.5X30X3.5-MM THK) | 50 |
