System And Components
352-5400 SERVICE CENTER GPS/N Z4Z1-382
Group No: 352-5400
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1487783 | 1 HOSE AS | 1 | |
| 2006345 | 2 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2467297 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2467298 | BRACKET | 1 | |
| 2516180 | 4 HOSE AS | 1 | |
| 2877301 | 5 VALVE-BALL | 1 | |
| 3072839 | 6 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3307220 | 7 TUBE AS | 1 | |
| 3307221 | 8 TUBE AS | 1 | |
| 3630594 | 9 HOSE AS | 1 | |
| 3883311 | 10 TUBE AS | 1 | |
| 3893799 | 11 HOSE AS | 1 | |
| 1488347 | 12 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488355 | 13 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488455 | 14 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 2042281 | 15 STRAP-CABLE | 4 | |
| 2P1293 | 16 LOCKNUT (1-3/16-12-THD) | 1 | |
| 4J0524 | 17 SEAL-O-RING | 1 | |
| 5K9090 | 18 SEAL-O-RING | 2 | |
| 5P7464 | 19 CLIP (SLOT) | 2 | |
| 5P7465 | 20 CLIP (TAB) | 2 | |
| 5P7468 | 21 CLIP (SLOT) | 5 | |
| 5P7469 | 22 CLIP (TAB) | 5 | |
| 5P7470 | 23 CLIP (SLOT) | 1 | |
| 5P7471 | 24 CLIP (TAB) | 1 | |
| 5P8182 | 25 GROMMET (46-MM ID) | 1 | |
| 5P8444 | 26 GROMMET (37-MM ID) | 1 | |
| 5P9299 | 27 CLIP (LOOP) | 3 | |
| 5S6981 | 28 RETAINER | 1 | |
| 6V0545 | 29 GROMMET | 1 | |
| 6V1874 | 30 GROMMET (31-MM ID) | 3 | |
| 6V7359 | 31 GROMMET (25-MM ID, 37-MM OD) | 2 | |
| 6V8398 | 32 SEAL-O-RING | 2 | |
| 6V8400 | 33 SEAL-O-RING | 2 | |
| 7M8485 | 34 SEAL-O-RING | 1 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 36 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4139 | 37 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4182 | 38 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4186 | 39 BOLT (M10X1.5X40-MM) | 5 | |
| 8T4195 | 40 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4223 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
