System And Components
8X-1732 SHUTOFF GP-MECHANICALS/N 9YF1-27
Group No: 8X-1732
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X4744 | 1 BRACKET AS | 1 | |
| 8G0863 | BLOCK | 1 | |
| 8T4121 | 2 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 3 BOLT (M10X1.5X20-MM) | 3 | |
| 0338248 | 4 CLIP (LOOP) | 6 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 9X9111 | 6 CABLE AS | 1 | |
| 8C4663 | HANDLE | 1 | |
| 5T4090 | 7 LEVER AS | 1 | |
| 4S5477 | BUSHING | 1 | |
| 9S1303 | 8 PIN | 3 | |
| 3B4607 | PIN-COTTER | 3 | |
| 1M0644 | 9 BOLT (3/8-16X2.25-IN) | 1 | |
| 1B2578 | NUT (3/8-16-THD) | 1 | |
| 2M4036 | 10 ROD END | 2 | |
| 1B4201 | 11 NUT-FULL (1/4-28-THD) | 3 | |
| 7L4981 | 12 ROD | 1 | |
| 8B3768 | 13 ROD END | 1 | |
| 6G9052 | 14 ADAPTER | 1 | |
| 4M5280 | 15 NUT-PLATED FULL (5/16-18-THD) | 1 | |
| 5S7379 | 16 BOLT (3/8-16X0.875-IN) | 2 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3B4617 | 17 PIN-COTTER | 1 | |
| 8W2920 | 18 PIN | 1 | |
| 5B2183 | 19 NUT-JAM (9/16-18-THD) | 1 | |
| 5P8246 | 20 WASHER-HARD (15.5X29X3-MM THK) | 1 |
