System And Components
8X-0014 CONTROL GP-AIR STARTINGS/N 9YF104-UP
Group No: 8X-0014
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2058262 | 1 HOSE AS | 1 | |
| 4D2847 | 2 HOSE AS | 1 | |
| 4H6147 | 3 CONNECTOR | 3 | |
| 4D7969 | 4 HOSE AS | 1 | |
| 4D5371 | 5 CLIP | 3 | |
| 5B7660 | 6 BUSHING-REDUCER | 1 | |
| 1L0766 | 7 ELBOW | 1 | |
| 8T4136 | 8 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8D9423 | 11 COUPLING | 1 | |
| 7I5513 | 12 PLATE AS | 1 | |
| 0026454 | 13 CONNECTOR | 1 | |
| 7D5207 | 14 PLUG | 1 | |
| 7D5208 | 15 FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 1L1722 | 16 CONNECTOR-PIPE | 2 | |
| 1159190 | 17 VALVE GP-RELAY (AIR STARTING MOTOR)(AIR START) | 1 | |
| 5H4778 | 18 ELBOW | 3 | |
| 0394966 | 19 ADAPTER | 2 | |
| 8T4205 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T9364 | 21 BOLT (1/4-20X0.625-IN) | 2 | |
| 5T4434 | 22 VALVE AS-SOLENOID (AIR START) | 1 | |
| 7D6081 | VALVE AS | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3S6115 | 23 TEE | 1 | |
| 8X5816 | 24 HOSE AS | 1 | |
| 8X5820 | 25 BRACKET | 1 | |
| 8T4179 | 26 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 2058261 | 28 HOSE AS | 1 | |
| 5P7466 | 29 CLIP (SLOT) | 1 | |
| 5P7467 | 30 CLIP (TAB) | 1 | |
| 8T4195 | 31 BOLT (M10X1.5X30-MM) | 1 | |
| 6D4244 | 32 CLIP (LOOP) | 1 | |
| 8X5815 | 33 HOSE AS | 1 | |
| 4S6668 | 34 CLIP (TAB) | 3 | |
| 6D9856 | 35 HOSE AS | 1 | |
| 8T0854 | 36 GAUGE GP-PRESSURE | 1 | |
| 9M8662 | 37 COUPLING | 1 | |
| 7D5206 | 38 CAP-DUST | 1 | |
| 2H3940 | 39 ELBOW | 2 | |
| 3B6552 | 41 ELBOW-PIPE | 1 | |
| 4D9976 | 42 UNION | 1 | |
| 9M8406 | 43 CLIP (LOOP) | 2 | |
| 8T4137 | 46 BOLT (M10X1.5X20-MM) | 1 | |
| 6L5955 | 47 ELBOW | 1 | |
| 7X2539 | 48 BOLT (M8X1.25X110-MM) | 3 | |
| 7X0613 | 49 WASHER-HARD (8.8X25.5X5-MM THK) | 3 | |
| 1159191 | KIT-SEAL | 1 |
