System And Components
114-2821 CYLINDER GP-TILT -LHS/N 9YF1-UP
Group No: 114-2821
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1590888 | 1 CYLINDER AS | 1 | |
| 6E1776 | 1A CAP AS | 1 | |
| 1V7038 | 1B BUSHING | 1 | |
| 3G5022 | 2 LOCKNUT (4 1/2-12-THD) | 1 | |
| 9J1159 | 3 RING-WEAR (260.3-MM ID) | 1 | |
| 1921455 | 4 SEAL AS | 1 | |
| 1142824 | 5 PISTON | 1 | |
| 5P2236 | 6 SEAL-O-RING | 1 | |
| 1647477 | 7 HEAD AS | 1 | |
| 1142822 | 8 ROD AS | 1 | |
| 1V7038 | 8A BUSHING | 1 | |
| 9X7420 | 9 RING-WEAR | 1 | |
| 1672725 | 10 SEAL AS-BUFFER | 1 | |
| 1672938 | 11 SEAL-U-CUP | 1 | |
| 1672993 | 12 SEAL-WIPER | 1 | |
| 1922057 | 13 RING-BACKUP | 2 | |
| 1577244 | 14 RING-BACKUP | 1 | |
| 1010767 | 15 BOLT (M36X4X150-MM) | 2 | |
| 3S6162 | 16 WASHER-HARD (40.5X67X6-MM THK) | 8 | |
| 1013672 | 17 BOLT (M36X4X120-MM) | 6 | |
| 9S4182 | 18 PLUG (7/16-20-THD) | 2 | |
| 3J7354 | 19 SEAL-O-RING | 2 | |
| 8L9241 | 20 SEAL-O-RING | 1 |
